Attaching The H2 Cabled Handle - Microscan HE45T Quick Start Manual

The HE45T features a variety of accessories including ruggedized
handles. For more information or for technical support, see the
Preface of the HE45T User Manual.

Attaching the H2 Cabled Handle

The HE45T uses the battery compartment to "snap to" the handle.
Figure 1–1 shows the H2 handle with flexible connector.
Figure 1–2 shows the battery blank.
FIGURE 1–1.
FIGURE 1–2.
To attach the handle to the reader:
2
H2 Handle with Flexible Connector
H2 Handle with Battery Blank
HE45T Quickstart Guide
Flexible Connector
Rev 2.0.0, Jan 2009
