Attaching the H2 Cabled Handle

The HE40T uses the battery compartment to "snap to" the handle.
Figure 1–1 shows the H2 handle with flexible connector.
Figure 1–2 shows the battery blank.
FIGURE 1–1.
FIGURE 1–2.
To attach the handle to the reader:
Push the 8-pin DIN connector at the end of the reader into the
1.
flexible connector at the end of the handle, as shown in
Figure 1–3.
2
H2 Handle with Flexible Connector
H2 Handle with Battery Blank
HE40T Quickstart Guide
Flexible Connector
