Trigger Programming

Left Trigger

FIGURE 1–40.

Right Trigger

FIGURE 1–41.
24
Left Trigger Programming Codes
Read With Both Imagers (Default)
Read With Far-Field Imager
Read With Near-Field Imager
Right Trigger Programming Codes
Read With Both Imagers (Default)
Read With Far-Field Imager
Read With Near-Field Imager
