FIGURE 1–11.
Reset to Factory
Defaults
Scan the QuickConnect code you received.
2.
The HE45T will automatically connect. By default, the HE45T
3.
will beep once after it connects and beep three times in a row if
it did not connect.
Scan the Save Settings code (Figure 1–12) to the right if you
4.
want to save the wireless connection settings to the HE45T so
that the HE45T will automatically try to connect wirelessly the
next time it is powered on.
FIGURE 1–12.
Save Settings

Radio Range and Transferring Data

The HE45T radio is a Class 1 device. If connected to another Class
1 device, the unit has roughly a 300 foot line of sight operating
range. If connecting to a Class 2 or Class 3 device, the operating
range may drop to match the lower range. Once a unit is connected,
the application software on the host must be open to receive data.
When the HE45T detects the radio is out of range, the HE45T will
store data on the reader's non-volatile memory.
For more information about setting up and using the HE45T with a
wireless Bluetooth configuration, consult the HE45T User Manual.
Rev 2.0.0, Jan 2009
Reset to RF Factory Defaults Code
Save Settings
HE45T Quickstart Guide
QuickConnect (Sample)
Scan the QuickConnect code
that matches the Bluetooth
address of your device
7
