FIGURE 1–26.
Status Bar
Soft Key Commands
Soft Keys
Press to Turn on
& Scan
Navigation Buttons

How to Scan Codes

Make sure the HE45T screen is at the Ready prompt
1.
(Figure 1–27).
Hold the HE45T a few inches away from a code (Figure 1–27).
2.
Press one of the red scan buttons or the trigger on the optional
3.
handle (Figure 1–27).
The HE45T will display data from the scanned code on its
screen (Figure 1–27).
Note: By default, data is sent to the host computer if the
HE45T is connected to it; data is stored in the HE45T's
memory if it can't be immediately sent to the host computer.
See the HE45T Display User Manual for more information on
storing and sending data.
FIGURE 1–27.
14
HE45T Layout
Turning On the HE45T
HE45T Quickstart Guide
Press to Turn on
& Scan
