HE45T Quickstart Guide
Rev 2.0.0, Jan 2009
EM-20953-1V200

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the HE45T and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Microscan HE45T

Summary of Contents for Microscan HE45T

  • Page 1 HE45T Quickstart Guide Rev 2.0.0, Jan 2009 EM-20953-1V200...
  • Page 2 (425) 226-5700 FAX: (425) 226-8682 All rights reserved. The information contained herein is proprietary and is provided solely for the purpose of allowing customers to operate and/or service Microscan manufactured equipment and is not to be released, reproduced, or used for any other purpose without written permission of Microscan.
  • Page 3 Limitation of Liability In no event shall Microscan Systems Inc. be liable to you or any third party for any special, incidental, or consequential damages (including, without limitation, indirect,...

  • Page 5: Table Of Contents

    RS-232 Cable Settings 12 Baud Rates 12 Save Settings 13 HE45T Display 13 How to Turn On the HE45T 13 How to Scan Codes 14 How to View Stored Data 15 How to Delete Stored Data 15 How to Transfer Stored Data to a Host Computer 16...
  • Page 6 Trigger Programming 24 Left Trigger 24 Right Trigger 24 Handle Trigger 25 Turbo Dot Peen Mode 25 Miscellaneous Programming Codes 26 Prefix Settings 26 Suffix Settings 27 Volume and Vibration Settings 29 Minimum Requirements 29 HE45T Quickstart Guide Rev 2.0.0, Jan 2009...

  • Page 7: Preface

    The purpose of the manual is to get you up and running quickly and confidently with your reader. Laser Safety Caution Laser in the HE45T LASER RADIATION - AVOID LONG TERM VIEWING OF DIRECT LASER RADIATION - LASER CLASS 2M Wavelength 630 nm - Maximum radiant power: < 1mW...

  • Page 8: Manual Conventions

    The following typographical conventions are used throughout this manual: • Items emphasizing important information are bolded. • Menu selections, menu items and entries in screen images are indicated as: Operation, Configure, etc. viii HE45T Quickstart Guide Rev 2.0.0, Jan 2009...

  • Page 9: Getting Started

    Getting Started CHAPTER 1 The HE45T establishes a new benchmark for Portable Data Terminals and Hand Held computers by combining the industry’s best imaging technology with a graphic display and rugged keyboard to create the smallest and lightest full-featured bar code reading terminal on the market.

  • Page 10: Attaching The H2 Cabled Handle

    For more information or for technical support, see the Preface of the HE45T User Manual. Attaching the H2 Cabled Handle The HE45T uses the battery compartment to “snap to” the handle. Figure 1–1 shows the H2 handle with flexible connector. Figure 1–2 shows the battery blank.
  • Page 11 Snap the reader onto the handle, matching the battery compartment to the battery connectors, visible inside the handle, as shown in Figure 1–3. The HE45T can be secured further with threaded screws on the under side of the handle, as shown in Figure 1–4. Location of Threaded Screws FIGURE 1–4.

  • Page 12: Attaching The Bh1/Bh2 Battery Handle

    Attaching the BH1/BH2 Battery Handle The HE45T uses the battery compartment to “snap to” the handle. The BH1/BH2 handle is shown in Figure 1–5. The handle with battery is shown in Figure 1–6. BH1/BH2 Handle FIGURE 1–5. BH1/BH2 Handle with Battery FIGURE 1–6.

  • Page 13: He45T Wireless

    Attaching the BH1/BH2 Handle FIGURE 1–7. The HE45T can be secured further with threaded screws on the under side of the handle, as shown in Figure 1–8. Location of Threaded Screws FIGURE 1–8. HE45T Wireless ® This HE45T features a Bluetooth wireless radio.

  • Page 14: Connecting With A Quickconnect Code

    Bluetooth adapter, make sure to note the Virtual COM Port number the software assigned for the adapter (e.g. COM 10). This is the COM Port your HE45T will connect through. To connect your reader: Scan the Reset to RF Factory Defaults code shown in Figure 1–11.

  • Page 15: Radio Range And Transferring Data

    Save Settings Radio Range and Transferring Data The HE45T radio is a Class 1 device. If connected to another Class 1 device, the unit has roughly a 300 foot line of sight operating range. If connecting to a Class 2 or Class 3 device, the operating range may drop to match the lower range.

  • Page 16: He45T Cables

    HE45T Cables The HE45T is available with USB, RS-232 and PS2 cables. All of the cables are connected to the HE45T with a 8-pin DIN connector. Different cables may be required for different hosts. • HE45T with H2 Cabled Handle — The 8-pin DIN connection is at the bottom of the handle.

  • Page 17: Usb Cable Connection

    Figure 1–16. You DO NOT need to power off your host computer. Connecting the USB Cable FIGURE 1–16. Once properly connected to the host computer, the HE45T will power on and beep. The reader is shipped pre-configured. Rev 2.0.0, Jan 2009 HE45T Quickstart Guide...

  • Page 18: Ps2 Cable Connection

    Attach the PS2 cable to the HE45T. If you have a cabled keyboard, detach the keyboard cable from your computer and connect that same connector to the female connection on the HE45T PS2 cable, as shown in Figure 1–17. Connecting the Keyboard Cable FIGURE 1–17.

  • Page 19: Rs-232 Cable Connection

    The HE45T is powered by the PS2 port and does not require a power supply. Once properly connected to the host computer, the HE45T will power on and beep. The reader is shipped pre- configured. RS-232 Cable Connection Attach the RS-232 cable to the HE45T.

  • Page 20: Ps2 Cable Settings

    Reset to PS2 PS2 Mode Factory Defaults All other PS2 settings can be found in the HE45T User Manual. RS-232 Cable Settings RS-232 One Way Mode — Data is sent from the Reader as serial data through the RS-232 port.

  • Page 21: Save Settings

    19200 4800 9600 38400 115200 57600 (Default) Save Settings Save changes made to the HE45T configuration by scanning the code in Figure 1–24: Save Settings FIGURE 1–24. Save Settings HE45T Display HE45T Display FIGURE 1–25. How to Turn On the HE45T Press and hold one of the red scan buttons for one second.

  • Page 22: How To Scan Codes

    Make sure the HE45T screen is at the Ready prompt (Figure 1–27). Hold the HE45T a few inches away from a code (Figure 1–27). Press one of the red scan buttons or the trigger on the optional handle (Figure 1–27).

  • Page 23: How To View Stored Data

    How to View Stored Data Scanned data will be stored on the HE45T if it is not connected to a host computer or if it is set to store scanned data. Use these steps to view data stored on the HE45T.

  • Page 24: How To Transfer Stored Data To A Host Computer

    FIGURE 1–29. How to Transfer Stored Data to a Host Computer Make sure the HE45T is attached to a host computer by cable or by a wireless Bluetooth connection. The HE45T screen should be at the Ready prompt. Press the CLEAR button to return to the Ready prompt if necessary (Figure 1–30).

  • Page 25: How To Lock/Unlock The Keypad

    Press the SHIFT key and the up arrow key at the same time. Locking & Unlocking the Keypad FIGURE 1–33. HE45T Display User Manual More information and instructions are available in the HE45T Display User Manual. Rev 2.0.0, Jan 2009 HE45T Quickstart Guide...

  • Page 26: Targeting And Reading Techniques

    Targeting and Reading Techniques The HE45T utilizes digital camera technology to take a picture of a symbol. Once an image is captured, the HE45T utilizes Microscan’s industry leading decoder to extract data from the captured image. The H2 Cabled Handle and BH1/BH2 Battery Handle each feature a trigger on the handle.

  • Page 27: Programming Codes

    The entire HE45T decode zone varies between two (2”) and twenty (20+”) or more inches. Hold the HE45T Reader still - DO NOT SWIPE OR MOVE THE READER. Press the trigger until the HE45T beeps, indicating the bar code has been successfully decoded.
  • Page 28 Code 39 Off Code 39 On I 2 of 5 On UPC On UPC Off I 2 of 5 Off UPC Extension Off UPC Extension On QR/Micro QR Off QR/Micro QR On Save Settings HE45T Quickstart Guide Rev 2.0.0, Jan 2009...

  • Page 29: Dod Uid Settings

    UII/CPN/LBN, HE45T stops image acquisition without an output string. • UII/CPN DM with Data Fields — The HE45T is configured to construct UII/CPN/LBN with all the data fields. • UII DM with Data Field — The HE45T is configured to construct UII and output additional data fields.

  • Page 30: Batch Mode

    UII/CPN Off Save Settings Batch Mode The HE45T unit features a batch mode for applications requiring a portable reader. Batch mode allows a user to store scanned data to the reader’s non-volatile memory. You may transfer the data to a host computer when needed.

  • Page 31: Auto Transfer Buffer Memory

    Auto Transfer Buffer Memory By default, when reconnected, the HE45T will automatically transfer any data in memory once a connection to a host is established. If your application is not ready, the reader will send the data anyway and the data could be lost. If you do not wish for the reader to immediately send data upon connection, please scan the Disable Auto Transfer Buffer Memory.

  • Page 32: Trigger Programming

    Read With Both Imagers (Default) Read With Far-Field Imager Read With Near-Field Imager Right Trigger Right Trigger Programming Codes FIGURE 1–41. Read With Both Imagers (Default) Read With Far-Field Imager Read With Near-Field Imager HE45T Quickstart Guide Rev 2.0.0, Jan 2009...

  • Page 33: Handle Trigger

    Read With Near-Field Imager Turbo Dot Peen Mode The HE45T with the default settings offers the best overall performance for Data Matrix DPM reading. For reading dot peen marks with cell size larger than 15 mils or 0.015 inches, it is often possible to improve the reading performance by enabling the Turbo Dot Peen mode.

  • Page 34: Miscellaneous Programming Codes

    Scan the codes in Figure 1–44 and Figure 1–45 to set the appropriate prefix: Prefix Codes FIGURE 1–44. Prefix - Comma Prefix - Space Prefix - Tab Prefix - Carriage Return (RS-232) Line Feed (RS-232) HE45T Quickstart Guide Rev 2.0.0, Jan 2009...

  • Page 35: Suffix Settings

    Scan the codes in Figure 1–46 and Figure 1–47 to set the appropriate suffix: Suffix Codes FIGURE 1–46. Suffix - Space Suffix - Comma Suffix - Enter Suffix - Carriage Return (USB/PS2) Line Feed (RS-232) Rev 2.0.0, Jan 2009 HE45T Quickstart Guide...
  • Page 36 Suffix Codes (Continued) FIGURE 1–47. Suffix - Carriage Return Suffix - Line Feed (RS-232) (RS-232) Suffix - Tab Suffix - Tab (RS-232) (USB/PS2) Save Settings Suffix - Erase/None This code will erase all suffix code HE45T Quickstart Guide Rev 2.0.0, Jan 2009...

  • Page 37: Volume And Vibration Settings

    Vibrate On Beep Off Beep On Beep On Save Settings Reader ID & Firmware Version Minimum Requirements Operating Systems: Windows© 2000, XP Interfaces: USB, RS-232, and PS2 Bluetooth™: HE45T only supports Bluetooth serial profile Rev 2.0.0, Jan 2009 HE45T Quickstart Guide...
  • Page 38 HE45T Quickstart Guide Rev 2.0.0, Jan 2009...
