Page 1: Operating Instructions
3228C/3235C/3245C Operating Instructions General Settings Guide Getting Started Combined Function Operations Document Server User Tools (System Settings) Troubleshooting Remarks Entering Text Specifications Read this manual carefully before you use this machine and keep it handy for future reference. For safe and correct use, be sure to read the Safety...
Page 2 (For details, see P.15 “Machine Types”.) • Type 1: Aficio 3228C • Type 2: Aficio 3235C • Type 3: Aficio 3245C Certain types might not be available in some countries. For details, please contact your local dealer.
Page 3 Manuals for This Machine The following manuals describe the operational procedures of this machine. For particular functions, see the relevant parts of the manual. Note ❒ Manuals provided are specific to machine type. ❒ Adobe Acrobat Reader/Adobe Reader is necessary to view the manuals as a PDF file.
Page 4 ❖ ❖ ❖ ❖ Scanner Reference (PDF file - CD-ROM1) Describes operations, functions, and troubleshooting for the machine's scan- ner function. ❖ ❖ ❖ ❖ Manuals for DeskTopBinder Lite DeskTopBinder Lite is a utility included on the CD-ROM labeled “Scanner Driver and Document Management Utility”.
Page 5: What You Can Do With This Machine
What You Can Do with This Machine The following introduces the functions of this machine, and the relevant manu- als containing detailed information about them. Products marked with * are optional. For details about optional products, see p.164 “Options”, or contact your local dealer. Copier, Facsimile, Printer, and Utilizing Stored Documents Scanner Functions...
Page 6: Paperless Fax Transmission And Reception
Paperless Fax Transmission Fax Transmission and and Reception Reception Through the Internet Reception ADL008S • You can send fax documents through ADL003S e-mail by specifying the recipient's • You can store received fax messag- e-mail address (Internet Fax Trans- es on the machine's hard disk, in- mission).
Page 7: Using The Scanner In A Network Environment
Using the Scanner in a Administrating the Network Environment Machine/Protecting Documents (Security Functions) ADL005S • You can send scanned documents to other network computers using ADL006S e-mail (Sending stored scan file by • You can protect documents from e-mail). See Scanner Reference. unauthorized access and stop •...
Page 8: Monitoring The Machine Via Computer
Monitoring the Machine Via Computer ADL007S You can monitor machine status and change settings using a computer. • Using SmartDeviceMonitor for Admin, SmartDeviceMonitor for Client, or a Web browser, you can use a computer to view the ma- chine's status, such as to check on paper quantities, or misfeeds, etc.
Page 9: Table Of Contents
TABLE OF CONTENTS Manuals for This Machine ..................i What You Can Do with This Machine..............iii Copier, Facsimile, Printer, and Scanner Functions........... iii Utilizing Stored Documents..................iii Paperless Fax Transmission and Reception............. iv Fax Transmission and Reception Through the Internet ..........iv Using the Scanner in a Network Environment ............
Page 10 Printing Stored Documents ..................42 Deleting Stored Documents ..................45 Viewing Stored Documents Using a Web Browser ..........45 Downloading Stored Documents................46 Settings for the Document Server..............47 4. User Tools (System Settings) User Tools Menu (System Settings)..............49 Accessing User Tools (System Settings) ............
Page 11 Registering a Protection Code ................99 Registering a Protection Code To a Single User ............. 99 Registering a Protection Code To a Group User ...........100 Registering the Transfer Request ..............101 Registering a Transfer Station/Receiving Station ..........101 Changing a Registered Transfer Station/Receiving Station ........103 Deleting a Registered Transfer Station/Receiving Station ........104 Registering SMTP and LDAP Authentication..........
Page 12 Where to Put Your Machine ................146 Machine Environment ....................146 Moving........................146 Power Connection....................147 Access to the Machine ...................147 Maintaining Your Machine ................148 Cleaning the Exposure Glass.................148 Cleaning the Exposure Glass Cover ..............148 Cleaning the Auto Document Feeder..............148 Cleaning the Dustproof Glass ................149 Earth Leakage Breaker ..................
Page 13: Notice
Notice Notice To Wireless LAN Interface (optional) Users Notice to Users in EEA Countries This product complies with the essential requirements and provisions of Direc- tive 1999/5/EC of the European Parliament and of the Council of 9 March 1999 on radio equipment and telecommunications terminal equipment and the mu- tual recognition of their conformity.
Page 14: Copyrights And Trademarks
Copyrights and Trademarks Trademarks ® ® ® Microsoft , Windows and Windows NT are registered trademarks of Micro- soft Corporation in the United States and/or other countries. ® Acrobat is a registered trademark of Adobe Systems Incorporated. Bluetooth™ is a trademark of the Bluetooth SIG, Inc. (Special Interest Group) and is used by RICOH Company Limited under license.
Page 15: Information About Installed Software
Information about Installed Software expat • The software including controller, etc. (hereinafter "software") installed on this product uses the expat Version under the conditions mentioned below. • The product manufacturer provides warranty and support to the software of the product including the expat, and the product manufacturer makes the in- itial developer and copyright holder of the expat, free from these obligations.
Page 16 Redistribution and use in source and binary forms, with or without modifica- tion, are permitted provided that the following conditions are met: Redistributions of source code must retain the above copyright notice, this list of conditions and the following disclaimer. Redistributions in binary form must reproduce the above copyright notice, this list of conditions and the following disclaimer in the documentation and/or other materials provided with the distribution.
Page 17 • This product includes software developed by Jonathan Stone and Jason R. Thorpe for the NetBSD Project. • This product includes software developed by the University of California, Lawrence Berkeley Laboratory and its contributors. • This product includes software developed by Christos Zoulas. •...
Page 18 e) The source code of the Sablotron software is available at: http://www.ginger- all.com f) MPL 1.1 is available at: http://www.mozilla.org/MPL/MPL-1.1.html JPEG LIBRARY • The software installed on this product is based in part on the work of the In- dependent JPEG Group. SASL CMU libsasl Tim Martin...
Page 19 Copyright © 1990-2, RSA Data Security, Inc. All rights reserved. License to copy and use this software is granted provided that it is identified as the "RSA Data Security, Inc. MD4 Message-Digest Algorithm" in all material mentioning or referencing this software or this function. License is also granted to make and use derivative works provided that such works are identified as "derived from the RSA Data Security, Inc.
Page 20 Samba(Ver 2.2.2-ja-1.1) For SMB transmission, this machine uses Samba ver 2.2.2-ja-1.1 (hereinafter re- ferred to as Samba 2.2.2-ja-1.1). Copyright © Andrew Tridgell 1994-1998 This program is free software; you can redistribute it and/or modify it under the terms of the GNU General Public License as published by the Free Software Foundation;...
Page 21: How To Read This Manual
How to Read This Manual Symbols This manual uses the following symbols: R WARNING: This symbol indicates a potentially hazardous situation that might result in death or serious injury if you misuse the machine by not following the instruc- tions under this symbol. Be sure to read the instructions, all of which are includ- ed in the Safety Information section in the General Settings Guide.
Page 22: Safety Information
Safety Information When using this machine, the following safety precautions should always be fol- lowed. Safety During Operation In this manual, the following important symbols are used: R WARNING: Indicates a potentially hazardous situation which, if instructions are not followed, could result in death or serious injury. R CAUTION: Indicates a potentially hazardous situation which, if instructions are not followed, may result in minor or moderate injury or damage to property.
Page 23 R CAUTION: • Protect the machine from dampness or wet weather, such as rain and snow. • Keep the machine away from humidity and dust. Otherwise a fire or an elec- tric shock might occur. • Do not place the machine on an unstable or tilted surface. If it topples over, an injury might occur.
Page 24: Positions Of Labels And Hallmarks For R
Positions of Labels and Hallmarks for R WARNING and R R CAUTION This machine has labels for RWARNING and RCAUTION at the positions shown below. For safety, please follow the instructions and handle the machine as indicated. ADL009S...
Page 25: Energy Star Program
ENERGY STAR Program As an ENERGY STAR Partner, we have determined that this machine model meets the ENERGY STAR Guidelines for energy efficiency. The ENERGY STAR Guidelines intend to establish an international energy-saving system for developing and introducing energy-efficient office equipment to deal with environmental is- sues, such as global warming.
Page 26 Specifications Type 1 Type 2 Type 3 Low - Power Power consumption 130W 135W 135W mode Default interval 15 minutes Recovery Time 25 seconds Sleep mode Power consumption 20W or less Default interval 60 minutes Recovery time 99 seconds Duplex Priority 1 Sided→1 Sided ❖...
Page 27: Machine Types
Machine Types This machine comes in three models which vary in copy speed. To confirm which model you have, see the inside front cover. Type 1 Type 2 Type 3 Copy speed/B&W 28 copies/minute 35 copies/minute 45 copies/minute " × 11"K) "...
Page 29: Getting Started
1. Getting Started Guide to Components AFZ001S Exposure glass cover (optional) or Earth Leakage Breaker Auto Document Feeder (ADF) (op- Prevents electric shock. See p.150 “Earth tional) Leakage Breaker”. Lower the exposure glass cover over Ventilation holes originals placed on the exposure glass. If Prevents overheating.
Page 30: Ventilation Holes
Getting Started Control panel Paper tray See p.21 “Control Panel”. Load paper here. See p.111 “BLoading Paper”. Standard tray Paper tray unit (optional) Copied, printed paper or fax messages are delivered here. Load paper here. See p.111 “BLoading Paper”, p.19 “External Options”. Front cover Open to access the inside of the machine.
Page 31: External Options
Guide to Components External Options AFZ006S Left tray 2 Tray finisher If you select this as the output tray, copies Sorts, stacks, staples, and punches copies. will be delivered face down. *1 Finisher Shift Tray 1 *2 Finisher Shift Tray 2 Exposure glass cover Lower this cover over originals before Booklet finisher...
Page 32: Internal Options
Getting Started Internal Options Fax unit Allows you to use the facsimile function. IEEE 1394 interface board Connects to an IEEE 1394 cable. Bluetooth Allows you to expand the interface. File Format Converter Allows you to download documents from the Document Server stored by copier and printer functions.
Page 33: Control Panel
Control Panel Control Panel This illustration shows the control panel of a machine with options fully in- stalled. AFZ025S Screen contrast knob • Communicating: Communicating in- dicator. See “Control Panel”, Facsimile Adjusts display panel brightness. Reference <Basic Features>. { { { { User Tools/Counter} } } } key •...
Page 34 Getting Started { { { { Program} } } } key (copier/facsimi- { { { { #} } } } key le/scanner mode) Press to enter a numerical value. Press to register frequently used settings, Number keys or recall registered settings. Press to enter the number of copies and { { { { Clear Modes} } } } key data for a selected function.
Page 35: Display Panel
Control Panel Display Panel The display panel shows machine status, error messages, and function menus. The function items displayed serve as selector keys You can select or specify an item by lightly pressing them. When you select or specify an item on the display panel, it is highlighted thus .
Page 36: When The Authentication Screen Is Displayed
Getting Started When the Authentication Screen is displayed When Basic Authentication, Windows Authentication, or LDAP Authentication is set, the authentication screen is displayed. Unless a valid user name and pass- word are entered, operations are not possible with the machine. Note ❒...
Page 37 Control Panel Log Off Important ❒ To prevent unauthorized users from using the machine, always log off when you have finished using the machine. A A A A Press { { { { User Tools / Counter} } } } . ZFLS110E B B B B Press [Logout].
Page 38: Turning On The Power
Getting Started Turning On the Power This machine has two power switches. The main power indicator turns on. ❖ ❖ ❖ ❖ Operation switch (right side of the con- trol panel) Press to activate the machine. When the machine has finished warming up, you can make copies.
Page 39: Turning Off The Power
Turning On the Power A A A A Make sure the On indicator is not Turning Off the Power lit. B B B B A A A A Open the switch cover, and then Make sure the exposure glass cov- turn off the main power switch.
Page 40: Saving Energy
Getting Started Saving Energy - Auto Off The machine automatically turns it- self off when the job is finished, after - Energy Saver Mode a certain period of time has elapsed. This function is called “Auto Off”. If you do not use the machine for a certain period after an operation, or Note when you press the { { { { Energy Saver} } } }...
Page 41: Combined Function Operations
2. Combined Function Operations Changing Modes Note ❒ You cannot switch modes in any of the following situations: • When scanning in a fax message for transmission • During immediate transmission • When accessing User Tools • During interrupt copying •...
Page 42: System Reset
Combined Function Operations ❒ The copying screen is displayed as default after power on. You can change this default setting. See p.53 “Function Priority”. AFZ020S - System Reset The machine returns automatically to its initial condition when the job is fin- ished, after a certain period of time has elapsed.
Page 43: Multi-Access
Multi-Access Multi-Access You can carry out another job using a different function while the current job is being performed. Performing multiple functions simultaneously in this manner is called “Multi-accessing”. This allows you to handle jobs efficiently, regardless of how the machine is being used.
Page 44 Combined Function Operations Mode after you select Copy Facsimile Printer Mode before you select × × × ❍ ❍ $ $ | $ | | | | | $ $ $ $ $ | | | Copy Operations for Copying →...
Page 45: Document Server
Multi-Access Mode after you select Copy Facsimile Printer Mode before you select $ $ $ ❍ ❍ $ $ | $ | | | | | $ $ × × × | | | Document Server Operations for Document Server $ ×...
Page 46 Combined Function Operations...
Page 47: Relationship Between Document Server And Other Functions
3. Document Server Relationship between Document Server and Other Functions The following table describes the relationship between the Document Server and other functions. Where to store Printing stored Sending function Displaying a list documents documents documents Copy/Document Copy Available Available Not Available Server Document Serv-...
Page 48: Document Server Display
Document Server Document Server Display ❖ ❖ ❖ ❖ Document Server Main Display AFZ021S Operating status and messages. The operation keys The title of the currently selected The functions under which the screen. documents were stored. The numbers of originals, copies, and printed pages.
Page 49: Using The Document Server
Using the Document Server Using the Document Server ❒ Avoid using a single number or Storing Data consecutive numbers for a pass- word such as “0000” or “1234”, since the numbers like this are easy ❖ ❖ ❖ ❖ File name to guess, so using them will not Stored documents are automatically provide a worthwhile level of se-...
Page 50 Document Server A A A A E E E E Press the { { { { Document Server} } } } key. Make any required settings. Reference For details, see Copy Reference. F F F F Press the { { { { Start} } } } key. ZGJS776E The document is stored in the Doc- B B B B...
Page 51 Using the Document Server When no user names are registered When no user names are in the Address Book, the User registered in the Address Book (Destination) Name entry display appears. A Enter a new user name, and then press [OK]. Reference p.73 “Authentication Informa- tion”...
Page 52: Changing A Stored Document's File Name, User Name, Or Password
Document Server C C C C Press [File Management]. To set or change a password A A A A Press [Scan Original]. The Scan Original display appears. B B B B Press [Password]. D D D D Press [Change User Name], [Change File Name], or [Change Password].
Page 53: Searching For Stored Documents
Using the Document Server ❒ You can sort document names Note in the list by user name, file ❒ If a password is already set for name, or date. To sort docu- the document, enter that pass- ments, press [User Name], [File word, and then press [OK].
Page 54: Printing Stored Documents
Document Server D D D D To specify an unregistered user To search by file name name, press [Non-programmed A A A A Name]. Enter a user name, and Press the { { { { Document Server} } } } key. then press [OK].
Page 55 Using the Document Server B B B B ❒ If you print more than one set If you need to change print set- using the Sort function, you can tings, press [Print Settings]. check the print result by print- The Print Settings display appears. ing out only the first set.
Page 56 Document Server ❒ You can search for the docu- Changing the number of copies ment by using [Search by User during printing Name] or [Search by File Name] at the left top of the display. See p.41 “Searching for Stored Doc- Limitation ❒...
Page 57: Deleting Stored Documents
Using the Document Server ❒ You can sort document names ❒ You can delete multiple docu- in the list by user name, file ments at once. See p.40 “Select- name, or date. To sort docu- ing a Document”. ments, press [User Name], [File ❒...
