Table Of Contents

Table of Contents

DO NOT

use or place the transceiver in areas with tem-

peratures below -25°C or above +55°C or, in areas subject

to direct sunlight, such as the dashboard.

AVOID

operating the transceiver without running the vehi-

cle's engine. The vehicle's battery will quickly run out if the

transceiver is in transmission while the vehicle's engine OFF.

AVOID

placing the transceiver in excessively dusty envi-

ronments.

AVOID

placing the transceiver against walls. This will ob-

struct heat dissipation.

AVOID

the use of chemical agents such as benzine or al-

cohol when cleaning, as they damage the transceiver sur-

faces.

BE CAREFUL!

The transceiver will become hot when

operating continuously for long periods.

IMPORTANT!

Detailed installation notes for Icom mobile transceivers to

be fitted into vehicles are available. Contact your Icom

dealer or distributor.

IMPORTANT .................................................................................................... i

EXPLICIT DEFINITIONS ................................................................................. i

PRECAUTION ................................................................................................. i

TABLE OF CONTENTS .................................................................................. ii

1 PANEL DESCRIPTION .......................................................................... 1-7

I Front panel ............................................................................................ 1

I Function display ..................................................................................... 3

I Programmable function keys ................................................................. 4

2 OPERATION ......................................................................................... 8-10

I Turning power ON ................................................................................. 8

I Channel selection .................................................................................. 8

I Receiving and transmitting .................................................................... 9

3 BIIS OPERATION ............................................................................... 11-22

I Default setting ...................................................................................... 11

I Receiving a call .................................................................................... 11

I Transmitting a call ................................................................................ 13

I Receiving a message .......................................................................... 15

I Transmitting a status ........................................................................... 17

I Transmitting an SDM ........................................................................... 18

I Position data transmission ................................................................... 20

I Printer connection ................................................................................ 20

I PC connection ..................................................................................... 20

I Digital ANI ............................................................................................ 20

I Auto emergency transmission ............................................................. 21

I Stun function ........................................................................................ 21

I BIIS indication ...................................................................................... 21

I Horn output .......................................................................................... 21

I Priority A channel selection .................................................................. 22

4 SmarTrunk II™ OPERATION ............................................................ 23-24

I SmarTrunk II™ and conventional modes ............................................ 23

I SmarTrunk II™ operation .................................................................... 23

5 CONNECTION AND INSTALLATION ................................................ 25-30

I Rear panel description and connection ............................................... 25

I Supplied accessories ........................................................................... 26

I Mounting the transceiver ...................................................................... 27

I Optional unit installation ...................................................................... 28

I Antenna ................................................................................................ 30

I Fuse replacement ................................................................................ 30

I Cleaning .............................................................................................. 30

6 OPTIONS .................................................................................................. 31

7 DOC........................................................................................................... 32
