2.3 Electric Installation
This subsection describes how to connect 2N
Network (LAN) and how to connect supply voltage and the electric lock.
PCB Connectors
Description of Connectors
LAN
OUT1
RELAY1
TAMPER
POWER
RESET
LAN connector
12V/700 mA switched
output
Relay NO/NC contacts
Tamper switch
12V/1A DC power input
RESET button
