Exiting Self Test

The test loop continues updating the time and battery status and processing keystrokes.
To end the test, press <Clear>. The display returns to the Command Mode menu.

Memory Transfer Program

Command Mode includes a memory transfer utility that transfers data from a terminal to a
host PC for program troubleshooting. Programmers can analyze an application using tools
provided in the Series 3000 Application Development Kit and described in the Series 3000
Application Programmer's Reference Manual.

Hardware Setup

1. Turn off the terminal and host PC. Disconnect or unplug the cradle, if used.
Always turn off the terminal before attaching or removing cables or adapt-
ers.
2. Connect the terminal and host PC using the 3115 communications/charger
adapter. Plug the CCA's RJ41 connector in the terminal's base, and the DB25
connector in the host PC's communications port.
OR
Connect the host to a one- or four-slot cradle:
a. Plug the null modem's connector in the cradle's communications port.
b. Plug the other connector in the host's communications port.
c. Place the terminal in the cradle.
3. Power on the host PC.
4. Plug in the cradle, if used.
Error Recovery and Troubleshooting
