H. Install the Log Assembly
Log Set Assembly: LOGS-QFI30FB
Models: QFI30FB, QFI30FB-C
5 5
SRV2221-704
SRV2221-704
SRV2221-701
SRV2221-701
2 2
SRV2221-703
SRV2221-703
1
1
PILOT BRACKET
PILOT BRACKET
GRATE BAR
GRATE BAR
GRATE TINES
GRATE TINES
Figure 2. Reference Points for Log Placement
CAUTION: Logs are fragile, handle with care. Glass Rock (2201-853):Fill each light tray evenly with the glass rock.
LOG RESTS
LOG RESTS
AGAINST BACK
AGAINST BACK
OF FIREBOX
OF FIREBOX
CENTER LOG
CENTER LOG
OVER PILOT
OVER PILOT
BRACKET
BRACKET
Figure 4. Place Log #1
Log #1 (SRV2221-703): Position Log #1 as shown in Figure 4. See Figure 2 for additional points of reference. Center the
log over the pilot bracket. Pull the log forward until contact is made with burner.
Log #2 (SRV2221-701): Position Log #2 as shown in Figure 5. See Figure 2 and Figure 6 for additional points of reference.
The recessed area on the bottom of the log and the back right corner of the burner top mate.
SRV2221-707
SRV2221-707
7 7
SRV2221-705
SRV2221-705
6 6
SRV2221-706
SRV2221-706
4 4
SRV2221-702
SRV2221-702
3 3
LIGHT TRAYS
LIGHT TRAYS
LOG PINS
LOG PINS
1 1
Quadra-Fire • QFI30FB-C, QFI35FB-C • 2221-901 Rev. S • 2/15
Figure 1. Logs Installed
Figure 3. Install Glass Rock
FLAT SPOT
FLAT SPOT
FOR LOG #6
FOR LOG #6
Figure 5. Place Log #2
GLASS ROCK
GLASS ROCK
RECESSED
RECESSED
AREA OF LOG
AREA OF LOG
MATES WITH
MATES WITH
BURNER TOP
BURNER TOP
2 2
33
