Getting Started
A. Typical Appliance System
NOTICE: Illustrations and photos refl ect typical installations and are for design purposes only. Illustrations/diagrams are not
drawn to scale. Actual product may vary from pictures in manual
3 INCH FLEX LINERS
(SECTION 8)
GAS LINE (SECTION 9)
ACCESS THROUGH EXISTING
MASONRY OR WOODBURNING
FIREPLACE
Figure 4.1 Typical System
16
Installer Guide
VENT PIPE
(SECTION 8)
Quadra-Fire • QFI30FB-C, QFI35FB-C • 2221-901 Rev. S • 2/15
VERTICAL TERMINATION CAP
(SECTION 8.E)
MANTEL AND MANTEL LEG
SECTION 5.B AND 11.A
SURROUND OR FRONT NOT SHOWN
SECTION 2.D AND SECTION 8.
HEARTH
EXTENSION
