Quadra-Fire QFI30FB-C Owner's Manual page 19

TOP VIEW
A
B
Location
A Rear Width
B Front Width
C Glass Opening Width
D Glass Opening Height
E Height-Front
F Height-Rear
G** Unit Depth
H Venting Depth
* Note: If exhaust collar on insert and fi replace damper do not line up, add 4 inches (102 mm) to minimum
fi replace height for bends in vent pipe.
**Unit depth is measured to the back of the surround to give the depth needed for installation.
In addition to these dimensions, also reference Clearances and Mantel Projections (Section 5.B).
Figure 5.2 Fireplace Opening
G**
E
H
MINIMUM FIREPLACE SIZE
QFI35FB-C
Inches
25-1/2
35
31-1/2
20
24-7/8
22-1/4
18-1/4
13-3/8
Quadra-Fire • QFI30FB-C, QFI35FB-C • 2221-901 Rev. S • 2/15
FRONT VIEW
D
C
QFI30FB-C
Millimeters Inches
648 21-1/2
889 30-1/4
800 26-3/4
508 18
632 22-7/8
565 20-5/8
464 16-7/8
340 12-1/8
F
Millimeters
546
768
679
457
581
524
429
308
19
