VB2SX User Guide
SETTINGS GPS MENU
-
DYNAMIC MODE
Press'■' and then the '◄' and Press'■' and then the '◄' and
'►' buttons to select the '►' buttons to select the DGPS
required dynamics. settings.
HIGH DYNAMICS OFF
No DGPS applied – standard
Essential for brake testing and
lane changing manoeuvres. position accuracy 3m CEP
WAAS – position accuracy 1.8m
NORMAL
Select this for standard testing –
CEP
speed, distance, etc.
40CM – position accuracy
LOW DYNAMICS 40CM*
Select this for route mapping
20CM – position accuracy
and similar tests where the level
of dynamic response is not 20CM*
important.
*Note: These accuracies are only achievable in conjunction with a DGPS base station
OUTPUTS MENU (Channel 1 and 2)
DIGITAL 1
Press'■' and then the '◄' and Press'■' and then the '◄' and
'►' buttons to select output '►' buttons to select output
conditions for digital output 1 conditions for digital output 2
OUTPUT: OUTPUT:
PULSES PER METRE (velocity) PULSES PER METRE (velocity)
MAX VELOCITY (velocity) MAX VELOCITY (velocity)
MAX VALUE (Lat ACC & Long MAX VALUE (Lat ACC & Long
ACC) ACC)
MAX FREQUENCY (Lat ACC & MAX FREQUENCY (Lat ACC &
Long ACC) Long ACC)
TEST TEST
BACK BACK
DGPS MODE KALMAN FILTER
Press'■' and then the '◄' and
'►' buttons to set Kalmann filter
options.
POSITION LEVEL
Smoothes the positional data
VELOCITY LEVEL
Smoothes the velocity data
DIGITAL 2 ANALOGUE 1
Press'■' and then the '◄' and
'►' buttons to select output
conditions for analogue output 1
OUTPUT:
VALUE @ +5V
VALUE @0V (Velocity)
VALUE @ -5V (Lat ACC & Long
ACC)
TEST
BACK
BACK
Press'■' to return to the GPS
menu
ANALOGUE 2
Press'■' and then the '◄' and
'►' buttons to select output
conditions for analogue output 2
OUTPUT:
VALUE @ +5V
VALUE @0V (Velocity)
VALUE @ -5V (Lat ACC & Long
ACC)
TEST
BACK
Page 9 of 28
BACK
Press'■' to return to the main
menu
