Front Panel Controls

The VB2SX can be configured using the front panel buttons, which enables configuration without the need for a computer.
'■'
From the main screen, press the
Once in the configuration screen, press the '
'■'
to select the highlighted option. Some menus contain sub-menus, for example the Analogue and Digital Output menus
contain separate menus for each parameter.
Main Menu
SETTINGS
Press'■' and then the '◄' and
'►' buttons to enter settings
options sub-menus.
UNITS
USB MODE
CAN MODE
LOG OPTIONS
SERIAL RATE
GPS
TIME OFFSET
BACK
button to enter the configuration screen.
◄' ►'
and '
buttons to highlight the next or previous choice in any menu, and press
COLD START
Press'■' to perform a GPS cold Press'■' to enter the Smoothing
start options sub-menus
LAT ACC
LONG ACC
Press'■' to enter sub menu and
'◄' and '►' buttons to amend
smoothing levels in 0.1
increments.
SMOOTHING OUTPUTS
Press'■' to enter the outputs
options sub-menus.
DIGITAL 1
DIGITAL 2
ANALOGUE 1
ANALOGUE 2
Page 7 of 28
EXIT
Press'■' to exit the setup menu
and cause the settings to be
saved in EEPROM
