VB2SX User Guide
Connector 5 – CAN (First CAN Bus Connector, Serial Connection to GPS Engine)
Pin
1
2
3
4
5
Chassis
Connector 6 – SERIAL (Setup / Upgrade, Second CAN Bus Connector)
Pin
1
2
3
4
5
Chassis
Connector 7 – USB (Setup / Upgrade)
Pin
1
2
3
4
Chassis
Connector 8 / 9 – ANT A / ANT B (GPS Antenna A / B)
Pin
1
Chassis
I/O
Function
O
RS232 Tx GPS (Tx Data from GPS engine)
I
RS232 Rx GPS (Rx Data to GPS engine)
I/O
CAN High (Also direct connection to Connector 6 CAN High)
I/O
CAN Low (Also direct connection to Connector 6 CAN Low)
I/O
Power +
I
Ground
I/O
Function
O
RS232 Tx Serial Data transmit
I
RS232 Rx Serial Data receive
I/O
CAN High (Also direct connection to Connector 5 CAN High)
I/O
CAN Low (Also direct connection to Connector 5 CAN Low)
I/O
Power +
I
Ground
I/O
Function
I/O
USB–
I/O
USB+
I/O
Ground
I
Ground
I/O
Function
I
Signal
I
Ground
Page 25 of 28
