VB2SX User Guide
Outputs
CAN Bus
Bit rate
Identifier type
Data available
Analogue
Voltage range
Default setting *
Accuracy
Update rate
Inputs
CAN Bus
VCI CAN mode
Racelogic modules
mode
Digital
Brake/Event Trigger
On/Off Logging
control
125Kbits, 250Kbits
,500Kbits & 1Mbit
selectable baud rate
Standard 11bit or
extended 2.0A
Satellites in View, Latitude, Longitude, Velocity, Heading, Altitude, Vertical velocity, Distance, Longitudinal
acceleration & lateral acceleration, Distance from trigger, Trigger time, trigger Velocity
Digital
0 to 5Volts DC Frequency range
Velocity Default setting *
0.0125Volts per Km/h
(0 to 400Km/h)
0.1 Km/h
20Hz Accuracy
Update rate
* The range settings can be adjusted by the user in software or via the front panel buttons
Up to 16 channels from any external CAN module
Up to 24 channels from any combination of ADC02, ADC03, FIM02, TC8, Yaw sensor or CAN02
Selectable signal polarity. 16bit timer capture with 5μs resolution
Remote log control from hand-held switch
DC to 44.4Khz
25Hz per Km/h (0 to 400Km/h)
90 pulses per metre
0.1Km/h
20Hz
