VB2SX User Guide
Digital Inputs
The DIGITAL I/O socket contains the two digital inputs for the VB2SX. Digital input 1 is also referred to as the Brake trigger input. This input is connected to an
internal timer capture module that is able to record precisely an event time for use in brake distance calculation. This period of time is called the trigger event
time, and is logged as the value in milliseconds between the trigger event and the last GPS sample.
A hand-held brake trigger is also available to allow the user to record marker events in the VB2SX data file.
A remote logging on/off switch is also available for ease of use and when the front panel switch is not accessible.
Page 14 of 28
