XP0120 Enterprise IP Phone

Action URI

Opposite to Action URL, Action URI allows the phone to interact with web server
applications by receiving and handling HTTP GET requests. To simply verify this feature,
you can enter the following string into the browser address bar and press Enter:
http://192.168.10.5/cgi-bin/ConfigManApp.com?key=DNDOn
Then the phone with the IP Address of 192.168.10.5, if existed, will turn on DND.
Be aware that only predefined phone events are supported by the phone.
The following table provides the predefined phone events:
Phone Events
key=OK/key=ENTER
key=SPEAKER
key=F_TRANSFER
key=VOLUME_UP
key=VOLUME_DOWN
key=MUTE
key=F_HOLD
key=X
key=0-9/*/POUND
key=D1-D10
key=F_CONFERENCE
key=F1-F4
key=MSG
key=HEADSET
key=RD
key=UP/ DOWN/ LEFT/
RIGHT
key=Reboot
key=AutoP
key=DNDOn
key=DNDOff
key=ATrans=XXXX
key=BTrans=XXXX
key=CALLEND

Music on Hold

Music on hold (MOH) is the business practice of playing recorded music to fill the silence
that would be heard by telephone callers who have been placed on hold. To use this
feature, you should specify a SIP URI pointing to the Music on Hold Server account.
When a call is put on hold, the phone will invite this SIP URI to call the held phone to
Xorcom Ltd.
Using the Advanced Phone Functions
Press the √ key or Enter hot key
Press the Speaker key
Press the Transfer key
Increase the volume
Reduce the volume
Press the Mute key
Hold/Resume the call
Press the X key
Enter the DTMF number(include Numeric , * or # keys)
Press a DSS key
Press the Conference key
Press a hot key
Press the Message key
Press the Headset key
Press the Redial key
Press the navigation key
Reboot the phone
Check the auto provision
Enable DND
Disable DND
Attended Transfer to extension XXXX
Blind Transfer to extension XXXX
Press the Cancel or Reject hot keys
65
