XP0120 Enterprise IP Phone

URL Record

This key function allows you to achieve the call recording capability during the
conversation when follows the voice prompts.
1) During a conversation, press the DSS key to start recording.
2) Enable the Recording function, the recording icon will be flashing on the LCD.
3) Press the DSS key again to disable the recording function, the flashing recording
icon will be disappeared simultaneously.
4) Follow the voice prompts to listen to the recording.
To configure the key as URL Record via web user interface:
1) Click on DSS Keys->Memory Keys.
2) Select the desired DSS key.
3) Select URL Record from the pull-down list of Type.
4) Enter the server URL in the Value field.
5) Click Confirm to save the change.
Note:
During a conversation, press this type of DSS key to start the recording process. if the
other party hangs up, the phone will turn to idle state.

Multicast Paging

Multicast is the delivery of a message or information to a group of destination
simultaneously in a single transmission from the source creating copies automatically
in other network elements.
A multicast paging is essentially a predefined broadcast address that the phone is
programmed to listen to. Each phone can be configured to listen to as many as 10
different multicast IP addresses. The priority of the IP Addresses is equivalent to the
stream priority, 1 is the highest, 10 is the lowest. Streams with higher priorities will
overlap those with lower priorities.
Users can configure the phone to send (receive) a Real Time Transport Protocol (RTP)
stream to (from) pre-configured multicast address without involving SIP signaling.
To configure a DSS key for sending Multicast RTP stream via web user interface:
1) Click on DSS Keys->Memory Keys.
2) Select the desired DSS key.
3) Select Multicast Paging from the pull-down list of Type.
4) Enter the multicast address(es) (IP: port) in the Value field.
Xorcom Ltd.
Using the Advanced Phone Functions
58 www.xorcom.com
