Click on Account->Basic on the web user interface, you will find the following
parameters:
Field
Register Status
Account Active
Label
Display Name
Register Name
User Name
Password
SIP Server
When you have finished the Network and Account Setting configuration, the Register
Status Icons will show on the idle screen:
Registered successfully
Register failed
Registering
When all accounts register fail, phone will display "No Service" by default.
When the phone reboot, it will register automatically. If many phones register at the
same time, this will affect the server. Users can set the register power up time so that
the phone will random register automatically within the set time.
To configure the power up time via web user interface:
1) Click on Network->Advanced.
2) Scroll to Registration random field, and enter the time in the Registration
random field.
3) Click Confirm to save the change.
Note:
Should the IP PBX (SIP registrar) require an authentication, you will be prompted to
enter the correct password. Make sure you are using the appropriate input method or
enter the password via web user interface.

Configuring via Keypad

Network Settings: Press Menu->Settings->Advanced Settings, enter the
password, and select Network->WAN Port /PC Port/VLAN/Webserver
Type/802.1x Settings/VPN to configure the network settings.
Account Settings: Press Menu->Settings->Advanced Settings, enter the
password, and select Accounts to configure the account settings.
Refer to Configuring via Web Page above for the parameter details.
Xorcom Ltd.
It shows the register status of the phone.
You can choose enable/disable to set the account respectively.
It is showed on the LCD screen for users to identify the account.
It is showed as Caller ID when making a phone call.
It is authenticated ID for authentication, provided by ITSP.
It is provided by ITSP for registration.
It is provided by ITSP for registration.
Server for registration, provided by ITSP.
Description
