XP0120 Enterprise IP Phone
Field Name
Start IP Address
End IP Address
To configure PC Port settings via phone user interface:
1) Press Menu->Settings->Advanced Settings.
2) Enter the password required, scroll to Network and then press the Enter hot key.
3) Scroll to PC port and then press the Enter hot key.
4) If you select Bridge, it will save and return to the previous menu.
5) If you select Router, enter the IP address, subnet mask in the proper fields,
enable/disable DHCP server.
6) Press the Save hot key to save the change or the Back hot key to cancel.
To configure PC Port settings via web user interface:
Click on Network->Basic-> LAN to do the relating configuration. Contact your
system administrator for more information.

VLAN Setting

VLAN is a group of hosts with a common set of requirements that communicate as if
they were attached to the Broadcast domain, regardless of their physical location. The
following table lists the instruction of the field about the VLAN Setting.
Field Name
QoS
Local RTP Port
WebServer
To configure VLAN settings via phone user interface:
1) Press Menu->Settings->Advanced Settings.
2) Enter the password required, scroll to Network and then press the Enter hot key.
3) Scroll to VLAN and then press the Enter hot key.
4) Scroll to WAN Port and then press the Enter hot key.
5) Set the VLAN Status, and enter the VID Number, Priority.
6) Press the Save hot key to save the change or the Back hot key to cancel.
7) Refer to the steps above to set the PC Port option.
Xorcom Ltd.
Indicate the range of the IP address
Indicate the range of the IP address
When the network capacity is insufficient, QoS could provide
priority to users by setting the value.
Define the port for voice transmission.
Users can choose the WebServer type: Disable, HTTP, HTTPS, or
HTTPS & HTTP.
Using the Advanced Phone Functions
Description
Description
41 www.xorcom.com
