Ipv6 Static/Default Route Settings - D-Link DGS-3600 Series User Manual

The following fields can be set:
Parameter Description
IP Address Allows the entry of an IP address that will be a static entry into the Switch's Routing Table.
Subnet Mask Allows the entry of a subnet mask corresponding to the IP address above.
NULL Interface Tick the checkbox to select the null interface.
Gateway Allows the entry of an IP address of a gateway for the IP address above.
Allows the entry of a routing protocol metric representing the number of routers between the
Metric (1-65535)
Switch and the IP address above.
The user may choose among Primary, Backup, and Weight. If the Primary Static/Default Route
Backup State
fails, the Backup Route will support the entry. Please take note that the Primary and Backup
entries cannot have the same Gateway. If Weight is selected, use the text box on the right to
enter your own weight setting.
Click Apply to implement changes made.

IPv6 Static/Default Route Settings

A static entry of an IPv6 address can be entered into the Switch's routing table for IPv6 formatted addresses. To view the
following window, click L3 Features > Static/Default Route Settings > IPv6 Static/Default Route Settings.
This window shows the following values:
Parameter
IPv6 Address/PrefixLen
Interface
xStack DGS-3600 Series Layer 3 Gigabit Ethernet Managed Switch
Figure 8- 10. IPv4 Static/Default Route Settings – Add window
Figure 8- 11. IPv6 Static/Default Route Settings window
Description
The IPv6 address and corresponding Prefix Length of the IPv6 static route entry.
The IP Interface where the static IPv6 route is created.
155
