Status
Delete
To enter an IP Interface into the Switch's IPv4 Static/Default Route Settings window, click the Add button, revealing the
following window to configure:
The following fields can be set:
Parameter
IP Address
Subnet Mask
Gateway
Metric (1-65535)
Backup State
Click Apply to implement changes made.

IPv6 Static/Default Route Settings

A static entry of an IPv6 address can be entered into the Switch's routing table for IPv6 formatted addresses.
To view this window, click Administration > Routing Table > IPv6 Static/Default Route Settings, as shown below:
This window shows the following values:
®
DGS-3400 Series Layer 2 Gigabit Ethernet Managed Switch
Displays whether the entry is Active or Inactive.
Click the button to delete this entry from the IPv4 Static/Default Route Settings table.
Figure 2 - 41 Static/Default Route Settings – Add window
Description
Allows the entry of an IP address that will be a static entry into the Switch's Routing Table.
Allows the entry of a subnet mask corresponding to the IP address above.
Allows the entry of an IP address of a gateway for the IP route above.
Allows the entry of a routing protocol metric representing the number of routers between
the Switch and the IP address above.
The user may choose between Primary and Backup. If the Primary Static/Default Route
fails, the Backup Route will support the entry. Please take note that the Primary and
Backup entries can not have the same Gateway.
Figure 2 - 42 IPv6 Static/Default Route Settings window
