HOW TO USE
C. Ensure slack is removed from the lap straps by
pulling the shoulder harness straps through the
buckle tongues, then pull the Harness Adjustment
Strap to take up the slack in the harness, adjusting
to a firm but comfortable fit. Make
sure that the baby's arms and
legs are free and the crotch
strap is between the legs.
Check that the slack in straps
is minimal.
Do not use the restraint if
straps do not tighten and
contact Customer Service.
Hook the harness adjuster strap on to the
loop to prevent tripping over the strap.
CAUTION:
The end of the harness adjustment strap is connected to the cover to avoid tripping
over the end when carrying the Carrier. Ensure the harness adjustment strap hook
is attached when carrying the carrier.
WARNING: DO NOT LEAVE CHILDREN
UNATTENDED IN THE CAR.
CAUTION: A LOOSE HARNESS IS DANGEROUS
44
Instructions for Installation & Use - Series No. 40/A/2013
Pull Harness Straps
through the buckle in
direction of arrows
Pull harness adjustment
strap to remove slack.
PLACING BABY & INFANT CARRIER ONTO BASE
A. Position the Infant Carrier over the top of the
base. Make sure the Harness Adjustment Strap is
not caught between Infant Carrier and Base then
lower the Infant Carrier into position.
B. Push down on the Infant Carrier until an audible
click is heard. Pull upwards on the Infant Carrier
to check it is correctly locked into position.
IMPORTANT:
Lift again to check engagement.
C. Attach the top tether around the infant carrier by
feeding through the handle and onto the top tether
strap guides as shown.
D. The handle may be rotated into other positions if
needed although this may be difficult due to the
front seating position.
E. Always secure the loose end of the top tether
strap in the pocket an the top tether strap
to prevent it hanging out of the car or being
accessible by the child.
Instructions for Installation & Use - Series No. 40/A/2013
HOW TO USE
Click
Top Tether Strap guides
Top tether strap
