Suitable For Use - Britax UNITY Instructions For Installation & Use

SPECIAL FEATURES
ISOFIX COMPATIBLE
(WITH OPTIONAL ISOFLEX™CONNECTORS)
ISOFLEX™ Connectors are flexible attachment connectors for use in a vehicle with
ISOFIX low anchorages.
(Top Tether not shown for
illustration purposes)
ISOFLEX CONNECTORS (IF FITTED)
25. ISOFLEX Strap Adjuster Button
26. ISOFLEX Strap
27. ISOFLEX Strap Adjuster
28. ISOFLEX Connector Release Button
29. ISOFLEX Connector
30. Tension Indicator (Green when activated)
31. Insertion Guides
32. Green Indicator
18
Instructions for Installation & Use - Series No. 40/A/2013
25
26
28
32
29
27
30
31
To be used only in a rearward-facing position for an infant until their shoulder's reach the
shoulder height marker (approximately 12 months of age).
Continue to use this infant restraint until child reaches this limit.
Infants are at risk of serious injury if they face forward too early.
If the baby's neck muscles are unable to support their head, then the child should remain
rear-facing, choose a restraint that will suit larger babies in a rear-facing mode.
545mm
530mm
To ensure that the space is sufficient, the purchaser should check the measurements
between the vehicle's rear and front seats in which the child restraint is intended to be
used.
Ensure babies and toddlers are adequately shaded from direct sunlight through side or
rear windows.
Check the car is ventilated by opening windows or using the car's ventilation system
taking in external air. Recirculation setting is not suitable for providing ventilation.
Instructions for Installation & Use - Series No. 40/A/2013

SUITABLE FOR USE

19
