FAN1/2/3 Speed
Show you the current system fan1/2/3 speed.
Vcore +3.3V/+5V/+12V/VBAT(V)/5VSB
Show you the voltage of +3.3V/+5V/+12V.
Press <Esc> to return to the Main Menu page.
5.12 Frequency/Voltage Control
This section is to control the CPU frequency and Supply Voltage,
DIMM OverVoltage and AGP voltage.
CPU Clock Ratio Unlock
Use this item to unlock CPU multiplier.
CPU Clock Ratio
Use this item to select the CPU's frequency.
Auto Detect PCI Clk
The enabled item can automatically disable the clock source for a
PCI slot without a module, to reduce EMI (ElectroMagnetic
Interference).
Phoenix-Award BIOS Utility
IMB202 LGA775 ATX Board User's Manual
51
