Component
IRIS 1400 Cabinet
Monitor
Keyboard
Mouse
Transceiver
Table 3-1: IRIS Workstation Component Specifications

3.1 Hardware Components

Each IRIS Workstation system has four hardware components (see Figure 3-1).
• The Electronics Cabinet is a floor-standing unit with a 20-slot backplane
and a power supply. The Cabinet uses forced air cooling and is
mounted on casters.
• The Monitor is a high-resolution 19-inch color monitor.
• The Keyboard is an 83-key up-down encoded keyboard.
• The Mouse is a 3-button mouse.
• The Switch Box has 32 independently programmable switches and 32
independently programmable LED indicator lights. An 8 character
LED display gives status information for the Dial Box and the
Switch Box.
• The Dial Box (optional) has 8 independently programmable valuators
for sending analog information to an application program for the
IRIS Terminal.

3.2 Ethernet Equipment

The IRIS Workstation can be connected to an Ethernet local area network with
an Ethernet transceiver and drop cable.
• The Ethernet Transceiver connects the IRIS Workstation to the
Ethernet.
Version 1.0

3. IRIS Workstation Specifications

Height
29.0"
18.0"
1.5"
1.0"
2.0"
Width Length
18.0" 27.0"
20.0" 21.0"
19.0" 8.5"
2.0" 3.0"
7.0" 4.0"
Weight
200.0 lbs
97.0 lbs
5.0 lbs
0.5 lbs
0.8 lbs
