Hardware Installation
3. Connect the transceiver to the Ethernet cable.
4. Connect the male end of the drop cable to the Ethernet port on the
Cabinet I/O Panel.
5. Connect the female end of the drop cable to the transceiver.

4.8 Cabinet AC Power Connection

The Cabinet power socket is located on the Cabinet Power Panel.
CAUTION: Do not connect the IRIS Workstation to a
switched power outlet.
1. Connect the female end of the AC power cable to the power socket
on the Cabinet Power Panel (see Figure 3-4).
2. Connect the male end of the Cabinet power cable to an appropriate
outlet. See Table 2-1 for a specification of the power requirements
of the IRIS Workstation.

4.9 Cabinet to Dial and Switch Box Connection

The IRIS Workstation can be connected to an optional Dial and Switch Box for
sending information to an application program on the IRIS Workstation.
1. Connect the 37-pin flat cable from the port on the Dial Box to the
bottom left port on the Switch Box.
2. Connect the 9-pin cable from the top left port on the Switch Box to
Port 4
enabled in the following way. Edit the file /etc/inittab. Each line
corresponds to a device file in /dev and contains four fields separated
by colons. Find the line for port d3 and put a x in the second field.
This prevents a getty process from being run on the port.
3. Plug the 3-wire AC power cable on the Switch Box into the
convenience outlet on the Cabinet Power Panel.
Version 1.0
on the Cabinet I/O Panel. This RS-232 cable should be
IRIS WORKSTATION GUIDE 19
3A Max
