4 IRIS WORKSTATION GUIDE
Temperature
Relative humidity
Minimum clearance
Monitor desk space
Cabinet floor space
Power
Power consumption
Heat dissipation
Card slots
Table 2-1: IRIS Workstation Environmental Specifications
9. Compare the equipment included in the tray with the list in Section
3. If any parts appear to be missing, contact Silicon Graphics
Customer Service (see Section 1).
10. Cut the plastic straps on the white carton.
11. Open the top of the carton and remove the foam cap.
12. Lift the carton off of the Cabinet.
13. Lift the Cabinet off the base pallet and set it on the floor.
14. Remove the foam spacers.
15. The Cabinet is shipped inside a large plastic bag. Remove the
Cabinet from the bag.
16. Check for damage to the Cabinet.
17. Remove the front panel from the Cabinet and check that the boards
inside are firmly attached.
18. The Cabinet has four castors on its base that allow it to be rolled
across a surface. Roll it to the location where it will be used.
Category
Unpacking the IRIS Workstation Components
IRIS 1400
50 — 86F° (operating)
40 — 176F° (non-operating)
40 — 80%
3" all sides
36" width
30" length
24" width
33" length
29" height
115 volts
15 amps
60 hertz
single phase
two wires + ground
883 watts
1240 KVA
3012 BTU/hour
20
Version 1.0
