3.4 Pinout

2
POWER SUPPLY
Male Molex connector series 5569 vertical (no. 39-30-1020)
1
1 +24 Vdc
J7
2 GND
ATTENTION:
Respect power supply polarity.
Note: Power supply cable
The following fi gure shows the connector pinout of the power supply cable for the device:
Power supply cable
2 1
USB INTERFACE
Female USB type B connector
3 4
1 USB-VBUS
2 D -
3 D +
J12
4 GND
SH1 SHIELD
SH2 SHIELD
(in)
(in/out)
(in/out)
Female Molex connector
series 5557 (n.39-01-3022)
2
PIN Cable
color
1
1 Red
2 Black
User Manual
3. INSTALLATION
Signal
+24V
GND
VKP80II 19
