The following fi gure gives the limit positions of the paper roll related to the printer for a correct paper loading without
a paper roll holder support.
The direction of the paper will always form a maximum angle of 90 ° or -90 ° with the insertion plane of paper inside
the printer.
90° 90°
-90° -90°
