5.5 Hexadecimal dump

This function is used to diagnose the characters received through the communication port; the characters are printed
out both as hexadecimal codes and ASCII codes.
Once the self-test routine has fi nished, the printer enters Hexadecimal Dump mode. The printer remains in standby
until a key is pressed or characters are received through the communication port. For example, in the 200 dpi model,
for every 8 characters received, the hexadecimal and corresponding ASCII codes are printed out (if the characters
are underlined, the receive buffer is full).
Shown below is an example of a Hexadecimal Dump:
