5. CONFIGURATION
PRINT MODE
CHARS / INCH
SPEED / QUALITY
PAPER RETRACTING
NOTCH ALIGNMENT
NOTCH THRESHOLD
NOTCH DISTANCE
32 VKP80II
User Manual
Printing mode:
Normal D = enables printing in normal writing way
Reverse = enables printing rotated 180 degrees
Font selection:
A = 11 cpi, B = 15 cpi
D
A = 15 cpi, B = 20 cpi
A = 20 cpi, B = 15 cpi
NOTA: CPI = Characters Per Inch
Setting of printing speed and printing quality:
High Quality
D
Normal
High Speed
Setting of the "retract" function of the paper, with paper presence on ejector during
power-up:
D
Disabled = "retract" function disabled
Enabled = "retract" function enabled
NOTE: During power-up, if paper is present on the ejector and if this parameter is set to "Enabled", the
printer will retract the paper. Otherwise, if the parameter is set to "Disabled", the printer will eject the paper.
Alignment management:
D
Disabled = the notch alignment is not performed
Enabled = the notch alignment is performed
Threshold value (in percent) for the recognition of the presence of notch by the notch
sensor:
0,5 2,0 D 3,5
1,0 2,5 4,0
1,5 3,0 4,5
NOTE: If the "Notch Alignment" parameter is disabled, this parameter is not printed.
"Notch Distance" is the minimum distance (in mm) between the upper edge of ticket
and the notch.
The numeric value of the distance is made up with the following four parameters
for the setting of three digits (two for the integer part of the number and one for the
decimal part) and of the sign:
NOTCH DISTANCE [mm x 10]
NOTCH DISTANCE [mm x 1]
NOTE: For example, to set the notch distance to 15 mm, modify the parameters as follows:
Notch Distance [mm x 10] = 1
Notch Distance [mm x 1]
NOTE: If the "Notch Alignment" parameter is disabled, the parameters for the "Notch Distance" are
not printed.
NOTE: In Setup mode, it is possible to set the notch distance using a values range from 0mm to 39mm.
The maximum distance accepted is 32mm, so even if values from 33mm to 39mm are inserted, the
distance remains 32mm.
Setting the digit for tens:
0 D 2 4
1 3 5
Setting the digit for units:
D
0 2 4
1 3 5
= 5
6 8
7 9
6 8
7 9
