Connectors

2 Connectors
2.1

USB type B connector CN1

Figure 8.
Table 12.
Pin number
2.2

CAN D-type 9-pin male connector CN2

Figure 9.
Table 13.
Pin number
1, 4, 8, 9
16/46
USB type B connector CN1 (front view)
USB type B connector (CN1)
Description
1 VBUS(power)
2 DM
3 DP
CAN D-type 9-pin male connector CN2 (front view)
CAN D-type 9-pin male connector (CN2)
Description
NC
2 CANL
Pin number
4 GND
5, 6 Shield
Pin number
7 CANH
3, 5, 6 GND
UM0426
Description
Description
