ST STM3210B-EVAL User Manual page 43

UM0426
Table 25.
LQFP100
63
64
65
66
67
68
69
70
71
72
73
74
75
76
77
78
79
80
81
82
83
84
85
86
87
88
89
90
91
92
93
94
95
Evaluation board IO assignments
Pin name Type
PC6 I/O
PC7 I/O
PC8 I/O
PC9 I/O
PA8 I/O
PA9 I/O
PA10 I/O
PA11 I/O
PA12 I/O
PA13 I/O
NC
VSS_2 S
VDD_2 S
PA14 I/O
PA15 I/O
PC10 I/O
PC11 I/O
PC12 I/O
PD0 I/O
PD1 I/O
PD2 I/O
PD3 I/O
PD4 I/O
PD5 I/O
PD6 I/O
PD7 I/O
PB3 I/O
PB4 I/O
PB5 I/O
PB6 I/O
PB7 I/O
BOOT0 I
PB8 I/O
STM3210B-EVAL IO assignments
Level
Input Output
FT LED
FT LED
FT LED
FT LED
FT LCD backlight control
FT USART1 TX
FT USART1 RX
FT USB DM
FT USB DP
FT Debug TMS
FT Debug TCK
FT Debug TDI
FT IRDA TX
FT IRDA RX
FT SD CS
FT CAN RX
FT CAN TX
FT MC_TIM3_ETR pin 27
FT USART2 CTS
FT USART2 RTS
FT USART2 TX
FT USART2 RX
FT LCD_RS
TC Debug TDO
TC Debug TRST
TC Temperature SMBIA
FT Temperature SCL
FT Temperature SDA
FT Audio PWM
EVAL board IO assignment
43/46
