Schematics

3 Schematics
This section provides design schematics for the STM3210B-EVAL key features to help you
implement these features in your own application designs.
This section includes:
●
Overall schematics for the board, see
● MCU connections, see
●
EEPROM, USB, LED, CAN and temperature sensor, see
● USART1, USART2, IrDA, see
●
Audio amplifier and micro amplifier, see
● Joystick, LCD, tamper button, wakeup button, user button, see
●
Smartcard and MicroSD card,
● Motor control,
●
JTAG, SWD debugger, see
●
Power supply, see
●
Extension connectors, see
●
MB542 daughter board schematics, see
