Climate Control System
Fan Control Buttons
You can manually select the fan
speed by pressing the fan control
buttons: to increase the fan's
speed, or to decrease the fan's
speed.
Dual Button
Press the DUAL button to select
dual temperature control mode (see
page 200 ).
Mode Button
Use the MODE button to select the
vents the air flows from. Some air
will flow from the dashboard corner
vents in all modes; you can turn it off
with the dial below each vent. Each
time you press the MODE button,
the display shows the mode selected.
Press the button four times to see all
the modes.
196
Comfort and Convenience Features
FAN CONTROL BUTTONS
AIR CONDITIONING
BUTTON
DUAL BUTTON RECIRCULATION BUTTON
MODE BUTTON
