  • Page 2 WARNING YOUR VEHICLE CAN BE HAZARDOUS TO OPERATE. A collision or rollover can occur quickly, even during routine maneuvers such as turning and driv- ing on hills or over obstacles, if you fail to take proper precautions. For your safety, understand and follow all the warnings contained in this Operator's Guide and the labels on your vehicle.

  • Page 3: Important Information

    In Canada, products are distributed by Bombardier Recreational Products Inc. (BRP). In USA, products are distributed by BRP US Inc. The following trademarks are the property of Bombardier Recreational Prod- ucts Inc.: Can-Am™ DS 650 ® Rotax XP-S...
  • Page 4 FOREWORD Congratulations on your purchase of a The information and components/ new Can-Am™ ATV. It is backed by the system descriptions contained in this BRP warranty and a network of autho- document are correct at the time of rized Can-Am dealers ready to provide publication.

  • Page 5: Table Of Contents

    TABLE OF CONTENTS While reading this Operator’s Guide, remember that: WARNING Indicates a potential hazard that, if not avoided, could result in serious in- jury or death. NOTICE................7 INTRODUCTION .
  • Page 6 4) Parking Brake..............65 5) Multi-Function Switch .
  • Page 7 Coolant Replacement ............98 Air Filter Housing .
  • Page 8 STORAGE AND PRESEASON PREPARATION ....... 117 WARRANTY BRP LIMITED WARRANTY NORTH AMERICA: 2007 CAN-AM ATV . . . 120 BRP INTERNATIONAL LIMITED WARRANTY: 2007 CAN-AM ATV .

  • Page 9: Notice

    NOTICE This Operator's Guide has been pre- pared to acquaint the owner/operator of a new vehicle with the various ve- hicle controls, maintenance and safe operating instructions. It is indispens- able for the proper use of the product. This Operator's Guide uses the follow- ing symbols.

  • Page 10: Introduction

    INTRODUCTION Your dealer should have provided you The contents of this Operator's Guide with some basic information on the provide riding information which has particular controls and features of your been proven reliable by other users. new vehicle. Please take the time to They are not intended as a definitive study this Operator's Guide and all means of avoiding accidents.

  • Page 11: Safety Information

    SAFETY INFORMATION ____________ ____________ SAFETY INFORMATION...

  • Page 12: Special Safety Messages

    Operator's Guide. instructor. Contact an authorized Always keep both hands on the Can-Am dealer to find out about handlebars and both feet on the available training course nearest footrests of the vehicle during op- you or call the Specialty Vehicle In- eration.
  • Page 13 Never operate this vehicle on hills Always use proper procedures if too steep for the vehicle or for your you stall or roll backwards when abilities. Practice on smaller hills climbing a hill. To avoid stalling, before attempting larger hills. use proper gear and maintain a steady speed when climbing a hill.
  • Page 14 Specialty Vehicle Institute of Amer- ica (SVIA) at 1 800 887-2887 or in Canada, the Canada Safety Council (CSC) at 1 (613) 739-1535 ext. 227 or contact an authorized Can-Am dealer to find out about available training courses nearest you. ___________...

  • Page 15: Operation Warnings

    They should then regularly practice the skills learned in the course and the operating techniques described in this Operator's Guide. For more information about the training course, contact an authorized Can-Am dealer or call BRP at 1 (819) 566-3366. ____________ ___________...
  • Page 16 WARNING V00A01Q POTENTIAL HAZARD Failure to follow the age recommendations for this vehicle. WHAT CAN HAPPEN A lack of respect for this age recommendation can lead to severe injury or death of the child. Even though a child may be within the age group for which this vehicle is recommended, he may not have the skills, abilities, or judgment needed to operate this vehicle safely and may be involved in a serious accident.
  • Page 17 WARNING V00A02Q POTENTIAL HAZARD Carrying a passenger on this vehicle. WHAT CAN HAPPEN Greatly reduces your ability to balance and control this vehicle. Could cause an accident, resulting in harm to you and/or your passenger. HOW TO AVOID THE HAZARD Never carry a passenger.
  • Page 18 WARNING V00A03Q POTENTIAL HAZARD Operating this vehicle on paved surfaces. WHAT CAN HAPPEN The tires are designed for off-road use only, not for use on pavement. Paved surfaces may seriously affect handling and control of this vehicle, and may cause the vehicle to go out of control. HOW TO AVOID THE HAZARD Never operate this vehicle on any paved surfaces, including sidewalks, driveways, parking lots and streets.
  • Page 19 WARNING V00A04Q POTENTIAL HAZARD Operating this vehicle on public streets, roads or highways. WHAT CAN HAPPEN You can collide with another vehicle. HOW TO AVOID THE HAZARD Never operate this vehicle on any public street, road or highway, even a dirt or gravel one.
  • Page 20 WARNING V00A06Q POTENTIAL HAZARD Riding this vehicle without wearing an approved helmet, eye protection and protective clothing. WHAT CAN HAPPEN The following items concern all ATV's operator: – riding without an approved helmet increases the chances of a severe head injury or death in the event of an accident –...
  • Page 21 WARNING V00A07Q POTENTIAL HAZARD Riding this vehicle after consuming alcohol or drugs. WHAT CAN HAPPEN Could seriously affect your judgment. Could cause you to react more slowly. Could affect your balance and perception. Could result in an accident or death. HOW TO AVOID THE HAZARD Never consume alcohol or drugs before or while riding this vehicle.
  • Page 22 WARNING V00A08Q POTENTIAL HAZARD Operating this vehicle at excessive speeds. WHAT CAN HAPPEN Increases your chances of losing control of the vehicle, which can result in an accident. HOW TO AVOID THE HAZARD Always travel at a speed which is proper for the terrain, visibility and op- erating conditions, and your experience.
  • Page 23 WARNING V00A09Q POTENTIAL HAZARD Attempting wheelies, jumps and other stunts. WHAT CAN HAPPEN Increases the chance of an accident, including an overturn. HOW TO AVOID THE HAZARD Never attempt stunts, such as wheelies or jumps. Do not try to show off. ____________ ___________ SAFETY INFORMATION...
  • Page 24 WARNING POTENTIAL HAZARD Failure to inspect the vehicle before operating. Failure to properly maintain the vehicle. WHAT CAN HAPPEN Increases the possibility of an accident or equipment damage. HOW TO AVOID THE HAZARD Always inspect your vehicle each time you use it to make sure the vehicle is in safe operating condition.
  • Page 25 WARNING V00A0BQ POTENTIAL HAZARD Removing hands from handlebar or feet from the footrests during opera- tion. WHAT CAN HAPPEN Removing even one hand or foot can reduce your ability to control the vehicle or could cause you to lose your balance and fall off the vehicle. If you remove a foot from the footrests, your foot or leg may come into contact with the rear wheels, which could injure you or cause an accident.
  • Page 26 WARNING V00A0CQ POTENTIAL HAZARD Failure to use extra care when operating this vehicle on unfamiliar terrain. WHAT CAN HAPPEN You can come upon hidden rocks, bumps, or holes, without enough time to react. Could result in the vehicle overturning or loss of control. HOW TO AVOID THE HAZARD Go slowly and be extra careful when operating on unfamiliar terrain.
  • Page 27 WARNING V00A0DQ POTENTIAL HAZARD Failure to use extra care when operating on excessively rough, slippery or loose terrain. WHAT CAN HAPPEN Could cause loss of traction or vehicle control, which could result in an accident, including an overturn. HOW TO AVOID THE HAZARD Do not operate on excessively rough, slippery or loose terrain until you have learned and practiced the skills necessary to control this vehicle on such terrain.
  • Page 28 WARNING V00A0EQ POTENTIAL HAZARD Turning improperly. WHAT CAN HAPPEN Vehicle could go out of control, causing a collision or overturn. HOW TO AVOID THE HAZARD Always follow proper procedures for turning as described further in this Operator's Guide. Practice turning at low speeds before attempting to turn at faster speeds.
  • Page 29 WARNING V00A0QQ POTENTIAL HAZARD Operating on excessively steep hills. WHAT CAN HAPPEN The vehicle can overturn more easily on extremely steep hills than on level surfaces or small hills. HOW TO AVOID THE HAZARD Never operate this vehicle on hills too steep for the vehicle or for your abil- ities.
  • Page 30 WARNING V00A0FQ POTENTIAL HAZARD Climbing hills improperly. WHAT CAN HAPPEN Could cause loss of control or cause vehicle to overturn. HOW TO AVOID THE HAZARD Always follow proper procedures for climbing hills as described further in this Operator's Guide. Always check the terrain carefully before you start up any hill. Never climb hills with excessively slippery or loose surfaces.
  • Page 31 WARNING V00A0GQ POTENTIAL HAZARD Going down a hill improperly. WHAT CAN HAPPEN Could cause loss of control or cause vehicle to overturn. HOW TO AVOID THE HAZARD Always follow proper procedures for going down hills as described further in this Operator's Guide. NOTE: A special technique is required when braking as you go down a hill.
  • Page 32 WARNING V00A0HQ POTENTIAL HAZARD Improperly crossing hills or turning on hills. WHAT CAN HAPPEN Could cause loss of control or cause vehicle to overturn. HOW TO AVOID THE HAZARD Never attempt to turn the vehicle around on any hill until you have mas- tered the turning technique as described further in this Operator's Guide on level ground.
  • Page 33 WARNING V00A0IQ POTENTIAL HAZARD Stalling, rolling backwards or improperly dismounting while climbing a hill. WHAT CAN HAPPEN Could result in vehicle overturning. HOW TO AVOID THE HAZARD Use proper gear and maintain steady speed when climbing a hill. If you lose all forward speed: Keep your weight uphill.
  • Page 34 WARNING V00A0JQ POTENTIAL HAZARD Improperly operating over obstacles. WHAT CAN HAPPEN Could cause loss of control or a collision. Could cause the vehicle to overturn. HOW TO AVOID THE HAZARD Before operating in a new area, check for obstacles. Never attempt to ride over large obstacles, such as large rocks or fallen trees.
  • Page 35 WARNING V00A0KQ POTENTIAL HAZARD Skidding or sliding improperly. WHAT CAN HAPPEN You may lose control of this vehicle. You may also regain traction unexpectedly, which may cause the vehicle to overturn. HOW TO AVOID THE HAZARD Learn to safely control skidding or sliding by practicing at low speeds and on level smooth terrain.
  • Page 36 WARNING V00A0LQ POTENTIAL HAZARD Operating this vehicle through deep or fast flowing water. WHAT CAN HAPPEN Tires may float, causing loss of traction and loss of control, which could lead to an accident. HOW TO AVOID THE HAZARD Never operate this vehicle in fast flowing water or in water deeper than that specified further in this Operator's Guide.
  • Page 37 WARNING V00A0OQ POTENTIAL HAZARD Operating this vehicle with improper tires, or with improper or uneven tire pressure. WHAT CAN HAPPEN Use of improper tires on this vehicle, or operation of this vehicle with im- proper or uneven tire pressure, may cause loss of control, tire blow outs, tire to move around on its rim, and increases the risk of an accident.
  • Page 38 Never modify this vehicle through improper installation or use of acces- sories. All parts and accessories added to this vehicle should be approved by BRP and should be installed and used according to instructions. If you have questions, consult an authorized Can-Am dealer. ___________ ___________...
  • Page 39 WARNING V02A02Q POTENTIAL HAZARD Overloading this vehicle or carrying or towing cargo improperly. WHAT CAN HAPPEN Could cause changes in vehicle handling which could lead to an accident. HOW TO AVOID THE HAZARD Never exceed the stated load capacity for this vehicle including operator as well as other loads and added accessories.
  • Page 40 WARNING V03M01Q POTENTIAL HAZARD Transporting flammable or dangerous material can lead to explosions. WHAT CAN HAPPEN This can cause serious injury or death. HOW TO AVOID THE HAZARD Never transport flammable or dangerous material. While reading this Operator’s Guide, remember that: WARNING Indicates a potential hazard that, if not avoided, could result in serious in- jury or death.

  • Page 41: Riding The Vehicle

    RIDING THE VEHICLE To fully appreciate the pleasures and Not all vehicles are the same. Each excitement of riding this vehicle, there has its own unique performance char- are some basic rules and tips that you acteristics, controls and features. MUST follow.
  • Page 42 • Start engine, remove parking brake and drive forward slowly a few feet then apply all brakes individually to test them. Correct any problem you may have found before riding. See an autho- rized Can-Am dealer as necessary. ___________ ___________ SAFETY INFORMATION...

  • Page 43: Clothing

    Clothing Actual weather conditions should help you decide how to dress. However, it is important that the operator always wear the appropriate protective clothing and apparel, including an approved helmet, eye protection, boots, gloves, long sleeved shirt and pants. This type of clothing will provide you protection from some of the minor hazards you may encounter en route.

  • Page 44: Carrying Loads

    Carrying Loads Any load carried on the vehicle will affect the stability and control of the vehi- cle. For this reason, do not exceed the load limits of the vehicle's manufacturer. Always make sure the load is secured and cannot interfere with your proper con- trol.

  • Page 45: Design Limitation

    Observe the rule... “what you take in, carry out”. Do not litter. Do not start campfires unless you have permission to do so... and then only... away from dry areas. The hazards you may create on the trail may cause injury to others or yourself, even at a later date.

  • Page 46: Uphill Driving

    Uphill Driving Due to configuration, this vehicle has excellent climbing ability, so much so that tipover is possible before traction is lost. For example, its common to encounter terrain situations where the top of the hill has eroded to a point that the hill peak rises very sharply.
  • Page 47 To maintain proper control it is strongly advised that you keep your hands on the handlebar and within easy reach of all controls. The same holds true for your feet. To minimize the possibility of any leg or foot injury, keep your feet on the footrests at all times.
  • Page 48 V00A0VL Water will affect the braking ability of your vehicle. Make sure you dry the brakes by applying them several times after the vehicle leaves the water. Mud or marsh lands may be encountered near water. Be prepared for sudden “holes”...
  • Page 49 When riding in sand dunes it is advisable to equip the vehicle with an antenna type safety flag. This will help make your location more visible to others over the next sand dune. Proceed carefully should you see another safety flag ahead. Since the antenna type safety flag can snag and rebound on your body if caught, do not use it in areas where there are low hanging branches or obstacles.
  • Page 50 Uphill Keep your body weight forward towards the top of the hill. Keep your feet on the footpegs and shift into low gear then accelerate and when necessary, change gear quickly as you climb. Do not over-speed since this may cause the front of the vehicle to lift from the ground and fall back on you.
  • Page 51 Downhill Keep your body weight rearwards. Apply the brake gradually to prevent skidding. Do not “coast” down the slope using solely engine compression or in neutral gear. V00A0YL ____________ ___________ SAFETY INFORMATION...
  • Page 52 Side Hilling This is one of the most risky types of riding since it may drastically change the balance of the vehicle. It should be avoided wherever possible. If it is necessary to do so however, it is important that you ALWAYS keep your body weight on the upside of the slope...

  • Page 53: Routine Maintenance

    Part of your responsibility towards safety is to respect the contents of this Op- erator's Guide. It provides valuable advice on how to properly take care of your vehicle. If further assistance is required your authorized Can-Am dealer is always willing to help.

  • Page 54: Hang Tag

    HANG TAG This vehicle comes with a hang tag and labels containing important safety infor- mation. Any person who rides this vehicle should read and understand this information before riding. V02M0FL 704901107 vmo2006-005-009_en ___________ ___________ SAFETY INFORMATION...

  • Page 55: Important On Product Labels

    The following labels are on your vehicle and they should be considered perma- nent parts of the vehicle. If missing or damaged, they can be replaced free of charge. See an authorized Can-Am dealer. NOTE: The following illustrations used in this Operator's Guide are a general representation only.
  • Page 56 USA and Canada Models Label 3 Label 1 V02M05Y Label 4 V02M06Y Label 5 V01M01Z Label 2 V01M07Z Label 6 V01M02Z V02M0GY ___________ ___________ SAFETY INFORMATION...
  • Page 57 Other Countries in the World Label 7 Label 8 XXXX XXXXX.XXXXXX XXXXXXXXXXXXXX XXXXXXXXX XXXX XXXX vmo2007-002-002 vmo2006-014-003_a While reading this Operator’s Guide, remember that: WARNING Indicates a potential hazard that, if not avoided, could result in serious in- jury or death. ____________ ___________ SAFETY INFORMATION...
  • Page 58 ___________ ___________ SAFETY INFORMATION...

  • Page 59: Vehicle Information

    VEHICLE INFORMATION _____________________...

  • Page 60: How To Identify Your Vehicle

    These numbers are required by the authorized Can-Am dealer to complete warranty claims properly. No warranty will be allowed by BRP if the engine identification...

  • Page 61: Noise Emission Control System Regulation

    NOISE EMISSION CONTROL SYSTEM REGULATION Tampering with Noise Control System is Prohibited! U.S. Federal law and Canadian provincial laws may prohibit the following acts or the causing there of: 1. The removal or rendering inoperative by any person other than for purposes of maintenance, repair or replacement of any device or element of design incorporated into any new vehicle for the purpose of noise control prior to its sale or delivery to the ultimate purchaser or while it is in use or,...

  • Page 62: Emission Requirements

    EMISSION REQUIREMENTS The California Air Resources Board (CARB) requires that your vehicle complies with applicable exhaust emissions standards during its useful life, when operated and maintained according to the instructions supplied. A non-compliance Red Label (as well as a Green Label) is obtained annually during California Vehicle registration.

  • Page 63: Break-In Period

    10 hours or 30 days or 400 km (250 mi) after the purchase, whichever comes first, your vehicle be inspected by an authorized Can-Am dealer. This inspection will give you the opportunity to discuss the unan- swered questions you may have en- countered during the first hours of op- eration.

  • Page 64: Controls/Components/Instrument

    CONTROLS/COMPONENTS/INSTRUMENT NOTE: Some controls/instruments/equipment are optional. V02A19L ______________________...
  • Page 65 V02A1CM _____________________...

  • Page 66: Throttle Lever

    While reading this Operator’s Guide, remember that: WARNING Indicates a potential hazard that, if not avoided, could result in serious in- jury or death. WARNING This vehicle may exceed the per- formance of other vehicles you may have ridden in the past. This category S (sport) is a high performance vehicle for off road use only.

  • Page 67: Clutch Lever

    4) Parking Brake Located on right side of handlebar on the front brake lever. When applied, it temporarily prevents the vehicle from moving. Useful when the brake needs to be locked for example such as doing a K-turn, during transportation or when the vehicle is not in operation.

  • Page 68: Multi-Function Switch

    To release mechanism: Squeeze This switch is used to stop engine and front brake lever. Lever lock should as an emergency control. automatically return to its original po- NOTE: While engine can be stopped sition. Front brake lever should return by turning ignition key OFF, we recom- to rest position.

  • Page 69: Fuel Tank Cap

    6) Fuel Tank Cap Neutral Indicator Lamp (green) Unscrew counterclockwise and re- When the transmission is in neutral, move cap to allow fuel tank filling then the neutral indicator lamp light comes fully tighten clockwise. Engine Indicator Lamp (red) WARNING When the engine oil pressure is too Always stop engine before re- low or the engine temperature is too...

  • Page 70: Fuel Valve

    V02I0WZ 1. Front brake fluid reservoir 10) Fuel Valve Located on right side under fuel tank. It is a 3-position rotary valve: OFF, ON, RES. Rotate the knob to align its point- er with ON, OFF or RES. V02A0KY Stops fuel supply to carburetor. CAUTION: Improper opening of fu- CAUTION: Turn valve to OFF posi- el valve will restrict the flow of fuel.

  • Page 71: Tool Box

    12) Tool Box 13) Seat Latch The tool box is located in the service Located underneath rear end of seat. compartment, near the air filter hous- It allows the removal of seat to give ing. access to air filter housing and storage compartment.

  • Page 72: Footpeg

    V02L07Y V02K01Y 1. Seat tab 1. Foot brake pedal 2. Body hook NOTE: Braking effect is proportional WARNING to the force applied on the lever and to the type and condition of the terrain. Periodically verify the seat lock pin and tighten if needed.

  • Page 73: Tachometer

    V02I01Z 1. Engine/transmission oil tank cap WARNING The oil tank can be hot. Do not touch with your hands. V02G0RY 1. Auxiliary headlamps 18) Tachometer 20) Nerf Bar The tachometer is located on the left Located on each side of vehicle, in side of the control panel.

  • Page 74: Choke Knob

    To remove the radiator cap, press and turn it counterclockwise. Reverse the removal procedure to install. V02C4VY V02A1HY 22) Choke Knob UNDER SEAT, ON THE LH SIDE OF CARBURETOR Located under seat, on the LH side of 1. Off position the carburetor.

  • Page 75: Liquids

    CAUTION: Never use an engine oil with the API SM or ILSAC GF-4 classification, using these oils in Can-Am ATV wet clutch equipped vehicles will create clutch slippage. _____________________...
  • Page 76 CAUTION: Do not use other syn- thetic oil, synthetic blend oil or oil additives in Can-Am ATV wet clutch equipped vehicles. Other viscosity should be used if the average temperature is outside the range of the recommended oil. See chart below.

  • Page 77: Engine Coolant

    362) or with distilled water and an- quently requires coolant is the indica- tifreeze solution (50% water, 50% an- tion of leaks or engine problems. See tifreeze). an authorized Can-Am dealer. Coolant Level Coolant Replacement WARNING Refer to MAINTENANCE section.

  • Page 78: Brake Fluid

    NOTE: A low level may indicate leaks or worn brake pads. See an autho- rized Can-Am dealer. Front Brake Fluid Reservoir Turn steering in the straight-ahead po- sition to ensure reservoir is level.

  • Page 79: Operating Instructions

    Correct any problem you may have • Activate throttle control lever sever- found before riding. See an autho- al times to ensure it operates freely. rized Can-Am dealer as necessary. It must return to idle position when released. Starting the Engine •...

  • Page 80: Shifting The Transmission

    Press the engine start button and hold To upshift to a higher gear, put the until engine starts. end of your boot under gearshift lever and lift up the pedal one full Release the engine start button imme- stroke. To downshift, lean the tip of diately when engine has started.

  • Page 81: Post-Operation Care

    Remove key from ignition switch. Post-Operation Care When vehicle is used in salt-water environment (beach area, launching/ loading boats, etc.), rinsing the vehi- cle with fresh water is necessary to preserve vehicle and its components. Metallic parts lubrication is highly rec- ommended.

  • Page 82: Special Procedures

    3 to thorized Can-Am dealer as soon as 5 minutes before starting the engine. possible. NEVER START THE EN-...

  • Page 83: Cargo And Transportation

    CARGO AND TRANSPORTATION While reading this Operator’s Guide, remember that: WARNING Indicates a potential hazard that, if not avoided, could result in serious in- jury or death. Cargo – Secure the vehicle, using the appro- priate areas. See the following il- lustration.

  • Page 84: Troubleshooting

    Install clean dry spark plug. Start engine following usual starting procedure. – If engine continues to flood, contact an authorized Can-Am dealer. 3. No fuel to the engine (spark plugs dry when removed). – Check fuel tank level; turn fuel valve to ON (also try on RES). A failure of the carburetor may have occurred.
  • Page 85 – Let engine cool down before checking coolant level and refill if possible, refer to ENGINE COOLANT in LIQUIDS. – If overheating persists, contact an authorized Can-Am dealer. 5. Air filter/housing plugged or dirty. – Check air filter and clean if necessary.
  • Page 86 UNUSUAL ENGINE NOISE 1. Valve adjustment. – Contact an authorized Can-Am dealer. 2. Chain tensioner plugged. – Contact an authorized Can-Am dealer. 3. Timing chain wear. – Contact an authorized Can-Am dealer. VEHICLE CANNOT REACH FULL SPEED 1. Engine. – See ENGINE LACKS ACCELERATION OR POWER.
  • Page 87 ON position (do not restart engine yet). The radiator fan will cool the radiator. – Let engine cool down before checking coolant level and refill if possible, refer to ENGINE COOLANT in LIQUIDS. – Contact an authorized Can-Am dealer. _____________________...

  • Page 88: Specifications

    SPECIFICATIONS MODEL DS 650™ X ENGINE BRP – Rotax, 4 stroke. Double overhead Type camshaft engine, chain drive Number of cylinder Single cylinder Number of valves 4 bucket tappet-operated valves Displacement 652 cc (39.7 cu. in) Bore 100 mm (3.9 in) Standard Stroke 83 mm (3.3 in)
  • Page 89 MODEL DS 650™ X ELECTRICAL Make Denso Magneto generator Type 290 W @ 6000 RPM Ignition type CDI (Capacitor Discharge Ignition) Ignition timing Not adjustable Engine RPM limiter 7900 (any gear in forward) Make Type DR 8 EA Spark plug 0.6 to 0.7 mm (.024 to .027 in) Number of spark plug Type...
  • Page 90 MODEL DS 650™ X TIRES Pressure Front 34.5 kPa (5 PSI) maximum (up to 100 kg 21 kPa (3 PSI) minimum Rear (220 lb)) Front 22 x 7 x 10 Size Rear 20 x 10 x 9 WHEELS 10 x 5.5 with Front reinforced ring Size...
  • Page 91 (engine and transmission) XP-S 5W40 synthetic oil. Do not use other synthetic oil, synthetic blend oil or additive in Can-Am ATV wet clutch equipped vehicles. Refer to OIL VISCOSITY CHART for other grade Ethylene-glycol/water mix (50% coolant, 50% distilled water).
  • Page 92 ______________________...

  • Page 93: Maintenance Information

    MAINTENANCE INFORMATION _____________________...

  • Page 94: General

    NOTE: The following covers the maintenance items that can be performed by the customer if desired. Other items found in MAINTENANCE CHART must be performed by an authorized Can-Am dealer. ______________________...

  • Page 95: Maintenance Chart

    Can-Am dealer. PERIODIC MAINTENANCE CHART INITIAL INSPECTION 10 H OR 30 DAYS OR 400 KM (250 mi) (To be performed by an authorized Can-Am dealer. The initial maintenance is very important and must not be neglected.) A: ADJUST...
  • Page 96 PERIODIC MAINTENANCE CHART INITIAL INSPECTION 10 H OR 30 DAYS OR 400 KM (250 mi) (To be performed by an authorized Can-Am dealer. The initial maintenance is very important and must not be neglected.) A: ADJUST 25 H OR 1250 KM (800 mi)
  • Page 97 PERIODIC MAINTENANCE CHART INITIAL INSPECTION 10 H OR 30 DAYS OR 400 KM (250 mi) (To be performed by an authorized Can-Am dealer. The initial maintenance is very important and must not be neglected.) A: ADJUST 25 H OR 1250 KM (800 mi)
  • Page 98 PERIODIC MAINTENANCE CHART INITIAL INSPECTION 10 H OR 30 DAYS OR 400 KM (250 mi) (To be performed by an authorized Can-Am dealer. The initial maintenance is very important and must not be neglected.) A: ADJUST 25 H OR 1250 KM (800 mi)

  • Page 99: Engine/Transmission

    ENGINE/TRANSMISSION Among other things, this section gives the procedures to replace the liquids. Refer to LIQUIDS for procedures to check levels and refill. Oil Change and Oil Filter Replacement Oil and filter are to be replaced at the same time. Oil change should be done with a warm engine.

  • Page 100: Coolant Replacement

    If the RED indica- the temperature sensor hole. tor lamp stays continually ON, stop the Install the temperature sensor and engine and see an authorized Can-Am continue the cooling system filling by dealer. the radiator. Ensure oil filter area, hose and drain Complete the radiator filling.

  • Page 101: Air Filter

    Release latches and remove air filter box cover. V02A0CY 1. Air filter housing V02A0DY 2. Drain tube 3. Clamp 1. Latches 2. Air filter box cover NOTE: If vehicle is used in dusty ar- Remove screw driver cap by pushing eas, inspect more frequently than it inside of air filter housing.

  • Page 102: Valves Adjustment

    Properly reinstall removed parts in the reverse order of their removal. V02C06Y 1. Screws Valves Adjustment 2. Spark arrester See an authorized Can-Am dealer for – spark arrester and sealant joint valves adjustment. Insufficient clearance will cause loss of power and possibly damage the valves.

  • Page 103: Radiator

    PRESSURE ONLY, DO NOT USE A place by a new one. Use Loctite HIGH PRESSURE WASHER. 5920 (RTV high temperature sealant) See an authorized Can-Am dealer to (P/N 293 800 090) or an equivalent check the performance of the cooling product.

  • Page 104: Clutch Cable Lubrication

    The release lever must locate on the WARNING spline in such a way that dimension A Always use a silicone-based lu- is obtained. See the following illustra- bricant. Using another lubricant tion. (like water-based lubricant) could NOTE: If necessary, unscrew the cause the clutch lever/cable stick- Allen socket screw and withdraw re- ing or stiffness.

  • Page 105: Fuel System

    FUEL SYSTEM Carburetor See an authorized Can-Am dealer each year or after using the vehicle 100 hours or after 5000 km (3100 mi) to verify and clean the fuel system. Throttle Cable Lubrication The throttle cable must be lubricated with cable lubricant (P/N 293 600 041) or an equivalent.

  • Page 106: Throttle Lever Adjustment

    NOTE: Measure throttle free play at the tip of throttle lever. Tighten lock nut and reinstall protector. V02I04Y 1. Throttle lever 2. Protector 3. Cable adjuster V00I03Y 4. Lock nut A. 3 to 8 mm (1/8 to 5/16 in) Insert the needle of spray can in the cable luber hole.

  • Page 107: Electrical

    ELECTRICAL WARNING Cleaning Clean battery post with a wire brush. Unless otherwise indicated, al- Apply dielectric grease (P/N 293 550 ways turn ignition switch to the 004) or an equivalent on post to pro- OFF position before performing tect against oxidation. any maintenance or repair on elec- trical system.

  • Page 108: Bulb Replacement

    V02G1NY – Detach bulb and replace. A15E0KY TYPICAL 1. Fuse 2. Check if melted Bulb Replacement WARNING Always turn the ignition switch to OFF position before replacing a de- fective bulb. Always check light operation after re- V02G1OY placement. Properly reinstall removed parts in the Headlamp reverse order of their removal.
  • Page 109 V02A06Y 1. Lens 2. Screws Push bulb in and hold while turning V02G0OY counterclockwise to release. 1. Remove these screws Install the new bulb by first pushing in Remove screw retaining the BLACK while turning clockwise. wire. Auxiliary Headlight Disconnect the auxiliary headlight then remove it from support.

  • Page 110: Indicator Lamp Replacement

    Tachometer The bulb in the tachometer is not re- placeable. If the tachometer bulb is burnt, replace the tachometer. See an authorized Can-Am dealer. Indicator Lamp V02G1QY Replacement 1. Headlamp 2. Adjusting screw...

  • Page 111: Drive Train

    Clean the side surfaces of the chain damages is detected DO NOT USE with a dry cloth. THE VEHICLE AND SEE AN AUTHO- RIZED CAN-AM DEALER. NOTE: Do not brush chain. Lubricate only with an approved O-ring WARNING chain lubricant.

  • Page 112: Drive Chain Slider

    Replace the drive chain slider when it NOTE: Correct chain free play adjust- is worn. ment is 19 to 25.4 mm (3/4 to 1 in) at See an authorized Can-Am dealer for midway between sprockets. replacement. Tighten the rear axle lock bolts to 23 N•m (17 lbf•ft).

  • Page 113: Tires/Wheels

    Push and pull the wheels from the up- altitude. Recheck pressure if one of per edge to feel the play. See an au- these conditions has changed. thorized Can-Am dealer if there is any For your convenience, a pressure play. gauge is supplied in tool box.

  • Page 114: Suspension

    Inspect shock absorber for oil leaks the shock absorbers. and fasteners for tightness. See an authorized Can-Am dealer as neces- NOTE: Do not remove the shock pro- sary. tectors if the vehicle is used on a grav- el surface.
  • Page 115 The rear shock includes a damper unit that contains high pressure nitrogen gas. Do not attempt to disassemble the damper. Do not dispose of it. See an authorized Can-Am dealer. V02A0WY 1. Rear bumper nut Spring Preload A. Measure between rear bumper...
  • Page 116 Preload Adjustment: Compression Damping: Turn shock spring Turn the damper adjuster reduce: adjuster counterclockwise reduce: counterclockwise for a light for a light load and smooth load and smooth condition. condition. Turn the damper adjuster Turn shock spring increase: clockwise for a firmer ride increase: adjuster clockwise...

  • Page 117: Brakes

    BRAKES Front and Rear Brakes The front and rear brakes are hydraulic disc types. These brakes are self- adjusting and require no adjustment. Check brake line fittings tightness be- fore every ride. _____________________...

  • Page 118: Body/Frame

    Check engine area for any damage Check frame for cracks or other dam- and leaks. Ensure all hose clamps age. See an authorized Can-Am dealer are properly secured and no hose is for replace or repair. cracked, kinked or otherwise dam- aged.

  • Page 119: Storage And Preseason Preparation

    CHART. When a vehicle is not in use for more than one month, proper storage is a necessity. See an authorized Can-Am dealer for proper procedures. When using your vehicle after storage, a preparation is required. See an au- thorized Can-Am dealer for proper pro- cedures.
  • Page 120 _____________________...

  • Page 121: Warranty

    WARRANTY _____________________...

  • Page 122: Brp Limited Warranty North America: 2007 Can-Am

    All genuine Can-Am ATV parts and accessories, installed by an authorized Can-Am dealer (as hereinafter defined) at the time of delivery of the 2007 Can-Am ATV, carry the same warranty as that of the Can-Am ATV. Use of the product for racing or any other competitive activity, at any point, even by a previous owner, will render this warranty null and void.
  • Page 123 3) CONDITIONS TO HAVE WARRANTY COVERAGE This warranty coverage is available only on 2007 Can-Am ATVs purchased as new and unused by its first owner from a Can-Am dealer authorized to distrib- ute Can-Am ATV products in the country in which the sale occurred (“Can-Am dealer”), and then only after the BRP specified pre-delivery inspection process...
  • Page 124 Can-Am dealer and gives the coordinates of the new owner; or b) BRP or an authorized Can-Am dealer receives a proof that the former owner agreed to the transfer of ownership, in addition to the coordinates of the new owner.
  • Page 125 If the issue has not yet been resolved, please submit your complaint in writing or call the appropriate number below: IN CANADA IN USA BOMBARDIER RECREATIONAL BRP US Inc. PRODUCTS INC. CAN-AM ATV CAN-AM ATV CONSUMER SERVICES GROUP CONSUMER SERVICES GROUP 7575 BOMBARDIER COURT VALCOURT QC J0E 2L0 WAUSAU WI 54401 Tel.: (819) 566-3366...

  • Page 126: Brp International Limited Warranty: 2007 Can-Am

    Can-Am distributor/dealer. Moreover, this warranty coverage is only available if the Can-Am ATV is purchased in the country in which the purchaser resides. BRP will not honor this limited warranty to any private use owner or commercial use owner if the preceding conditions have not been met.
  • Page 127 BRP’s obligations under this warranty are limited to, at its sole discretion, repair- ing parts found defective under normal use, maintenance and service; or replac- ing such parts with new genuine Can-Am ATV parts without charge for parts and labour, at any authorized Can-Am distributor/dealer.
  • Page 128 If the ownership of a product is transferred during the warranty coverage period, this warranty shall also be transferred and be valid for the remaining coverage period provided BRP or an authorized Can-Am distributor/dealer receives a proof that the former owner agreed to the transfer of ownership, in addition to the co-ordinates of the new owner.
  • Page 129 9) CONSUMER ASSISTANCE a) In the event of a controversy or a dispute in connection with this limited war- ranty, BRP suggests that you try to resolve the issue at the dealership level. We recommend discussing the issue with the authorized dealer's service manager or owner.

  • Page 130: Privacy Obligation/Disclaimer

    PRIVACY OBLIGATION/DISCLAIMER We wish to inform you that your coordinates will be used for safety and warranty purposes. Sometimes, we also use the coordinates of our clients to inform them about our products and to present them offers. Should you prefer not to receive information on our product, services and offers, please let us know by writing to the address below.

  • Page 131: Change Of Address/Ownership

    (715) 848-4957 (USA) or (819) STOLEN UNITS: If your personal ATV 566-3366 (Canada); is stolen, you should notify BRP or an authorized Can-Am dealer. We – notifying an authorized Can-Am will ask you to provide your name, dealer. address, phone number, the vehicle...
  • Page 132 _____________________...
  • Page 133 (715) 848-4957 (USA) or (819) STOLEN UNITS: If your personal ATV 566-3366 (Canada); is stolen, you should notify BRP or an authorized Can-Am dealer. We – notifying an authorized Can-Am will ask you to provide your name, dealer. address, phone number, the vehicle...
  • Page 134 _____________________...
  • Page 135 ATV MODEL No. VEHICLE IDENTIFICATION NUMBER (V.I.N.) ENGINE IDENTIFICATION NUMBER (E.I.N.) Owner: NAME STREET CITY STATE/PROVINCE ZIP/POSTAL CODE Purchase Date YEAR MONTH Warranty Expiry Date YEAR MONTH To be completed by the dealer at the time of the sale. DEALER IMPRINT AREA V00A2IL Please verify with your dealer to ensure your vehicle has been registered with BRP.

Table of Contents
