External Interface

Model
Audio/Video Input
Audio/Video Output
Sensor Input
Alarm Output
PTZ
ACC Wire Connection
GPS
Ethernet
USB
IR Receiver
Power
Alarm
Model
Sensor Input
Alarm Output
Environment
Model
Operation Temp.
Humidity
Reliability (for GV-LX4C3V only)
Operating Shock
Operating Vibration
Specifications: The Four-Channel Unit
GV-LX4C3D1 GV-LX4C3D2
D-Type, DB 15 connector (4 Videos In, 4 Audios In)
D-Type, DB 15 connector (1 TV Out, 1 Spot Out, 1 VGA Out, 1 Audio Out,
4 Video Loops Out)
4 inputs on terminal block
4 outputs on terminal block
RS-485 +/- outputs on terminal block
None
None
RJ-45, 10/100 Mbps
2 ports (USB 2.0)
1 port for optional External IR Receiver
12V, 5A (60 W Max.)
GV-LX4C3D1 GV-LX4C3D2
4 digital inputs
4 relay outputs
GV-LX4C3D1 GV-LX4C3D2
-20 ~ 50 °C (4 ~ 122 °F)
5 ~ 85% RH (non-condensing)
10G, 2 ms
5 ~ 500 Hz, 1G
GV-LX4C3V
GV-LX4C3D2W
(ACC Model)
GV-LX4C3V
GV-LX4C3D2W
(ACC Model)
GV-LX4C3V
GV-LX4C3D2W
(ACC Model)
