4.8.5 Spot Monitor Settings

You can configure the settings when a spot monitor is connected to the GV-Compact DVR V3.
NORMAL DWELL TIME: Select the amount of time that each video remains on the spot
monitor before the GV-Compact DVR V3 switches to the next video in a rotation. The
dwell time can be between 1 and 5 seconds.
TRIGGER DWELL TIME: Select the amount of time that the video remains on the spot
monitor after the motion or I/O triggered event occurs. The triggered dwell time can be
between 1 and 5 seconds.
TRIGGER INTERVAL: Select the interval between triggered events from 1 to 5 seconds.
During the specified length of time, all the triggered events will be ignored. The triggered
event after the interval will be displayed on the spot monitor.
MOTION SPOT: Select the cameras to be displayed upon motion events.
INPUT X: Select the associated camera to be displayed when an input is triggered.
94
Figure 4-45
