I I N N V V E E R R S S I I O O N N T T A A B B L L E E
OWNER'S MANUAL
MODEL#75118
CAUTION: Weight on this product should not exceed 136kgs (300lbs).
CAUTION: Exercise of a strenuous nature, as is customarily done on this equipment, should not be undertaken
without first consulting a physician. No specific health claims are made or implied as they relate to the
equipment. Measurements made by the equipment are believed to be accurate, but only the measurements of
your physician should be relied upon.
IMPORTANT:
Read all instructions carefully before using this product. Retain this owner's manual for future reference.
Instructions for assembly, including correct fitting of guards and other device, and warnings about the likely
injuries to young children if exercise equipments are operated in their vicinity without properly fitted guards.
Product may vary slightly from picture.
2011, Aug.
Advertisement
Table of Contents
Related Manuals for LifeGear 75118 Inversion table
Summary of Contents for LifeGear 75118 Inversion table
- Page 1 I I N N V V E E R R S S I I O O N N T T A A B B L L E E OWNER’S MANUAL MODEL#75118 2011, Aug. CAUTION: Weight on this product should not exceed 136kgs (300lbs). CAUTION: Exercise of a strenuous nature, as is customarily done on this equipment, should not be undertaken without first consulting a physician.
- Page 2 TABLE OF ONE YEAR WARNING CONTENTS LIMITED WARRANTY Warranty LifeGear Inc. warrants to the WARNING original purchaser that this Warning Before using this product, product is free from defects in Safety Precautions please consult your personal material and workmanship when...
- Page 3 SAFETY PRECAUTIONS This inversion table was designed and built for optimum safety. However, certain precautions apply whenever you operate the exercise equipment. Be sure to read the entire manual before assembling and operating this equipment. Also, please note the following safety instructions: 1.
- Page 4 SAFETY PRECAUTIONS...
-
Page 5: Overview
OVERVIEW DRAWING... -
Page 6: Parts List
PARTS LIST Part # Description Quantity Part # Description Quantity Front U-Frame Rubber Heel Holder Rear U-Frame Nylon Strap Adjustable Boom Loop Strap Bed Frame Strap Lock Pivot Arm Nylon Bed Adjustable lnstep Frame Foam Grip Steel Heel Holder Bracket Protective Cover Right Folding Arm Hex Head Bolt M8x23... -
Page 7: Bolt M8X23
HARDWARE PACKING LIST Part # Description Quantity Hex Head Bolt M6x47 ----------------------------------------------------------------------------------------2 Washer Ø 20xØ 8.5x1.5 --------------------------------------------------------------------------------------12 Lock Nut M8 ------------------------------------------------------------------------------------------------------6 Lock Nut M6 ------------------------------------------------------------------------------------------------------2 Washer Ø 16xØ 6.5x1.0 ----------------------------------------------------------------------------------------4 Hex Head Bolt M8x23 ----------------------------------------------------------------------------------------2 Hex Head Bolt M8x50 ----------------------------------------------------------------------------------------2 Square End Cap -------------------------------------------------------------------------------------------------- 1 Hex Head Bolt M8x38 ----------------------------------------------------------------------------------------2 Nut Cap Ø... -
Page 8: Assembly
ASSEMBLY INSTRUCTIONS STEP 1: Stand up the base of the machine by separating the u-frames. Pull the Front and Rear U-Frames (1, 2) as far apart from each others as possible. Then push down on the middle of the Left and Right Folding Arms (8L, 8R) until they are fully locked down. -
Page 9: Protective Cover
STEP 2: Install two Ø 27xØ 13.5 Nut Caps (48) onto M8 Lock Nuts (15). Slide one Protective Cover (37) on to each side of the base as shown, and pull down on the Protective Covers (37) until the bottom of the covers are slightly lower than the Left and Right Folding Arms (8L, 8R). - Page 10 STEP 3: Slide the bottom of the Pivot Arms (5) into the brackets that located at each side of the Bed Frame (4), align to the desired hole on the arm with the peg on the bracket. Insert the peg into the hole to lock the Pivot Arms (5) in place.
-
Page 11: Steel Heel Holder Bracket
STEP 5: Slide the Rod (9) through the large round hole on the side of the Adjustable Boom (3), and secure the Rod (9) on the Adjustable Boom (3) with one M6x47 Hex Head Bolt (11), one M6 Lock Nut (16), and two Ø... - Page 12 11 11 11 11 STEP 7: Attach the Adjustable Instep Frame (6) to the Adjustable Boom (3) by inserting the Adjustable Instep Frame (6) into the square bracket on the boom. Slide the Adjustable Instep Frame (6) completely into the square bracket, insert the M6x47 Hex Head Bolt (11) with a Ø 16xØ 6.5x1.0 Washer (27) halfway through the square bracket, slide the M6x47 Hex Head Bolt (11) through the ring at the bottom of the Spring (23), slide the M6x47 Hex Head Bolt (11) through the rest of the square bracket, and secure at the other end with a Ø...
- Page 13 STEP 8: Pull out the Large Spring Knob (18), and slide the Adjustable Boom (3) into the square bracket on the bottom of the Bed Frame (4) as shown. Slide the Adjustable Boom (3) upward until the desired height on the Height Scale (44) is just below the bracket on the bed frame. Lock the Adjustable Boom (3) in place by releasing the Large Spring Knob (18) and sliding the Adjustable Boom (3) up or down slightly until the Large Spring Knob (18) "pops"...
-
Page 14: Handlebar
STEP 9: Attach the top end of Handlebar (29) onto the Rear U-Frame (2) and Pivot Arm Ring (49) with one M8x 23 Hex Head Bolt (38), one M8 Lock Nut (15), and two Ø 20xØ 8.5x1.5 Washers (13). Attach the bottom end of the Handlebar (29) onto the Rear U-Frame (2) with one M8x38 Hex Head Bolt (43), one M8 Lock Nut (15), and two Ø... - Page 15 STEP 10: Attach the Nylon Strap (32) to the Strap Lock (34) by inserting the end of the Nylon Strap (32) up through the bottom of the Strap Lock (34), loop the Nylon Strap (32) over the Pre-assembled Loop Strap (33) and down through the Strap Lock (34). Now, loop the strap back over itself, and insert back through the Strap Lock (34), and pull tight to secure.
- Page 16 SAFETY OPERATING INSTRUCTIONS Correct Incorrect Pivot arm is NOT aligned correctly. Make sure the pivot arm is inserted all the The pivot arm is not inserted all the way into the slot. Pivot arm is aligned correctly way into the curved slot. when the groove sits directly on the curved slot and the pivot arm is able to rotate freely.
- Page 17 OPERATION AND ADJUSTMENTS LENGTHEN SHORTEN THE STRAP ADJUSTING THE STRAP For added safety, a nylon strap has been included to restrict the degree of inversion. This strap can be adjusted to different lengths to allow for a greater or lesser degree of inversion. To lengthen the Nylon Strap (32) feed the top end of Nylon Strap (32) into the strap lock, and pull on the lower end of the strap.
- Page 18 PIVOT ARMS The Pivot Arms (5) can be adjusted to allow for a greater or lesser degree of inversion. To adjust the Pivot Arms (5) simply pull out on them until the post is out of the hole, slide them up or down to the desired hole, push in until the post goes through the desired hole.
-
Page 19: Adjusting The Angle Holder
ADJUSTING THE ANGLE HOLDER Pull up on the Small Spring Knob (17), slide the Adjustable Instep Frame (6) upward. Stand on the Foot Bar (39) located at the bottom of the Adjustable Boom (3). Pull up on the Small Spring Knob (17), allow the Adjustable Instep Frame (6) to slide back into the Adjustable Boom (3). - Page 20 BALANCING THE INVERSION TABLE The inversion table is like a very sensitively balanced fulcrum. It responds to very slight changes in weight distribution. So, it is very important to make sure that the height is adjusted properly. To do this, mount the inversion table, lock your ankles into the rubber heel holders, and lie back with your hands at your sides.
- Page 21 SUGGESTIONS FOR USE 1. Begin slowly: invert only 15~20 degrees to begin with. Stay inverted only as long as you are comfortable. Return upright slowly. 2. Make gradual changes: increase the angle only if it is comfortable. Increase angle only a few degrees at a time.
- Page 22 STORAGE For your storage convenience, the inversion table can be folded down to place against a wall, under a bed, or in a storage area.
-
Page 23: Warm Up/Cool Down Routine
WARM UP AND COOL DOWN ROUTINE A good exercise program consists of a warm-up, aerobic exercise, and a cool down. Do the entire program at least two to three times a week, resting for a day between workouts. After several months you can increase your workouts to four or five times per week. - Page 24 SIDE STRETCHES Open your arms to the side and lift them until they are over your head. Reach your right arm as far toward the ceiling as you can for one count. Repeat this action with your left arm. QUADRICEPS STRETCH With one hand against a wall for balance, reach behind you and pull your right foot up.
- Page 25 TOE TOUCHES Slowly bend forward from your waist, letting your back and shoulders relax as you stretch toward your toes. Reach as far as you can and hold for 15 counts. HAMSTRING STRETCHES Extend your right leg. Rest the sole of your left foot against your right inner thigh.
Need help?
Do you have a question about the 75118 Inversion table and is the answer not in the manual?
Questions and answers
how to adjust for high and waight
To adjust the LifeGear 75118 inversion table for height and weight:
1. Height Adjustment:
- Ensure both Pivot Arms (5) are set to the same hole.
- If the inversion table does not return to the upright position when your hands are below your waist, it may not be adjusted correctly for your height.
2. Weight Limit:
- The maximum weight capacity for the inversion table is 136 kg (300 lbs).
- Ensure weight does not exceed this limit for safe use.
Proper adjustment ensures safe and effective operation.
This answer is automatically generated
Instead of just saying "attach the bed to the frame" it will be MUCH more helpful to show a picture with the best position to attach the bed into the frame. For the life of me I struggle with this EVERY time I take down and reassemble. Otherwise, great product.
