2. LIST OF ERROR DISPLAY / INDICATION

Errors are indicated by the LED, and warnings are displayed on the monitor of the computer connected to
the printer.
2-1. Operator Call Errors (by Alarm LED Blinking in Orange)
Alarm
LED
Error [Error code]
blinking
in orange
No paper. (ASF) [1000]
2 times
No CD / DVD tray. [1001]
No paper in the cassette.
[1003]
(No paper in the front paper
feed cassette.)
No CD / DVD disc. [1002]
Paper jam. [1300]
3 times
Paper jam in the rear guide.
[1303]
Paper jam in the under guide.
[1304]
Front door close error. [1250]
4 times No ink. [1600]
Ink tank not installed. [1660]
5 times The print head is not installed ,
or it is not properly installed.
Download Service Manual And Resetter Printer at http://printer1.blogspot.com
Solution
Set the paper in the ASF, and press the
Resume/Cancel button.
*1
Set the CD / DVD tray, and press the
Resume/Cancel button.
Set the paper in the cassette, and press
the Resume/Cancel button.
*1 Set a CD or DVD in the CD / DVD tray
(which is ejected at error occurrence),
and insert the CD / DVD tray in the
proper position. Then, press the
Resume/Cancel button.
Remove the jammed paper, and press
the Resume/Cancel button.
Open the paper output tray.
Replace the empty ink tank(s), or press
the Resume/Cancel button.
Install the applicable ink tank(s)
properly, and confirm that the LED's of
all the ink tanks light red.
Install the print head properly.
1-5
Remarks
Error in paper
feeding from the
ASF.
Error in the
duplex printing
unit.
Error in paper
feeding from the
cassette.
The error is
indicated if the
paper output tray
is closed at start
of a print job, or
while a print job
is being
performed.
Pressing the
Resume/Cancel
button will exit
the error without
ink tank
replacement,
however, ink
may run out
during printing.
