Canon PIXMA iP5200R Service Manual page 55

center.)
Remaining ink amount
Available (automatic detection by optical method and dot count, enabled at default)
detection
Paper type detection Not available
Available (automatic or manual alignment via driver utilities, or the Resume/Cancel
Print head alignment
button in Camera Direct Printing, automatic alignment at default)
*1: Only for CD / DVD printing supported regions
<Print head>
Type Single head with 5 removable ink tanks (each color)
Black: 512 nozzles (600dpi), 30pl (pigment-based black)
Print head
Color: 512 nozzles x 6 (1,200dpi), 1pl / 5pl (cyan, magenta), 5pl (black, yellow)
Ink color Pigment-based black, Dye-based black, cyan, magenta, yellow
Ink tank PGI-5BK (pigment-based), CLI-8BK/C/M/Y (dye-based)
Weight (Net) Print head, approx. 60g
Supply method As a service part (not including ink tanks)
Part number QY6-0061-000
<Supported ink tanks>
Model Destination
Overseas
PIXMA iP5200
models
O: Usable X: Not usable
Note:
The ink tanks BCI-9BK and BCI-7e series available in Japanese market are not compatible with the
PIXMA iP5200 overseas models.
Be sure to use the appropriate ink tanks in servicing.
Download Service Manual And Resetter Printer at http://printer1.blogspot.com
Pigment-
based
PIG-5BK CLI-8BK
O O
BCI-9BK BCI-7eBK
X X
<PIXMA iP5200 Specifications>
3-10
Dye-based
CLI-8C CLI-8M
O O
BCI-7eC BCI-7eM
X X
CLI-8Y
O
BCI-7eY
X
