value (ASF back side, U-turn front side, U-turn back side)*1
33. Print head temperature (BK/CL)
34. Inside temperature 35. Line inspection information
*1: not used for servicing
HDEEPROM
36. Version
37. Serial number
38. Lot number
39. Print head ID
40. Ink ejection level (PBK, BK, Y, M, M2, C, C2)
To the top
<Part 1: 3. REPAIR, 3-4>
1-33
