Canon PIXMA iP5200R Service Manual page 15

No printing, or no color ejected. Replace the
Printing is faint, or white lines
appear on printouts even after
print head cleaning.
Line(s) not included in the print
data appears on printouts.
Paper gets smeared.
A part of a line is missing on
printouts.
Unsatisfactory
Color hue is incorrect.
print quality
Printing is incorrect.
No ejection of black ink.
Graphic or text is enlarged on
printouts.
Download Service Manual And Resetter Printer at http://printer1.blogspot.com
- sheet feed unit, or
- cassette.
- ink tank,
*2
- print head , or
*1
- logic board ass'y ,
remove foreign material from the
purge unit caps, if any, or
replace the purge unit.
Remove and re-install the print head,
or replace the
- ink tank,
*2
- print head ,
- purge unit, or
*1
- logic board ass'y .
Feed several sheets of paper,
perform bottom plate cleaning,
clean the paper path with cotton swab
or cloth, or
clean the ASF sub-rollers.
Replace the
- ink tank, or
*2
- print head .
Replace the
- ink tank, or
*2
- print head , or
perform print head alignment.
Replace the logic board ass'y
Replace the
- ink tank, or
*2
- print head , or
remove foreign material from the
purge unit caps, if any, or
replace the purge unit.
When enlarged in the carriage
movement direction, clean grease or
oil off the timing slit strip film, or
replace the
- timing slit strip film,
- carriage unit, or
*1
- logic board ass'y .
When enlarged in the paper feed
direction, clean grease or oil off the
timing slit disk film, or replace the
1-10
*1
.
