Page 1: User Instructions
O I L F I R E D B O I L E R S Combi Range I N S T A L L A T I O N C O M M I S S I O N I N G S E R V I C I N G &... -
Page 2: Table Of Contents
CONTENTS FOREWORD INTRODUCTION Health & Safety Fuel Spillage First Aid TECHNICAL SPECIFICATIONS Boiler Dimensions Boiler Specifications & Recommendations Etc. Oil Burner Performance Specification Boiler control panel wring diagram 2e & f Riello oil burner specification & technical details Control panel layout OPERATING INSTRUCTIONS Boiler controls Operating procedure... -
Page 3: Introduction
FOREWORD INTRODUCTION This instruction manual is produced for the reference The Firebird Combi Boiler Range is based on the ‘S’ Range Boilers. All boilers in the range are designed and guidance of qualified installation engineers. EU and manufactured to meet all the latest European... -
Page 4: Health & Safety
HEALTH & SAFETY FUEL SPILLAGE INFORMATION Under the Consumer Protection Act 1987 and Switch off all electrical and other ignition Section 6 of the Health and Safety Act 1974, we are sources. required to provide information on substances Remove all contaminated clothing to safeguard hazardous to health. -
Page 5: Technical Specifications
TECHNICAL SPECIFICATION 2-A Diagrams Combi Range Dimensions Side View. Front View. Rear View. Top View. 1. Mains Feed. 2. D.H.W . 3. 3bar Safety Valve. 4. C.H. Flow. 5. C.H. Return. 50-70 & 70-90 90-120 840mm 155mm 840mm 155mm 610mm... -
Page 6: Technical Specification
TECHNICAL SPECIFICATION Pressure Jet Oil Burner Riello RDB or Ecoflam Flair or Bentone Sterling Fuel Kerosene Class C2 Domestic Hot Water Plate Heat Exchanger Giannoni Albion, SWEP or Alfa Laval Circulating Pumps Grundfos UPS 25/60 Flue Pipe Connection Conventional Flue Socket To take tail piece for 4”... - Page 7 TECHNICAL SPECIFICATION 2-C Burner Settings Firebird Boiler Range Kerosene Using RDB Range Of Burners (K). Variations in nozzle throughput, flue type & draught, oil viscosity etc. may give results differing from these laboratory performance figures. Range Burner Head Fuel Nozzle P.P.
- Page 8 TECHNICAL SPECIFICATION 2-D Wiring Diagram Combi Range...
- Page 9 TECHNICAL SPECIFICATION 2-E&F Riello Burner Specification Burner Description One stage kerosene and oil burner. In case of BF applications the intake air temperature must not be over 70C The burner meets protection level of IP 40, EN 60529. Burnerwith CE marking in conformity with EEC directives: EMC 89/336/EEC, Low Voltage 73/23/EEC, Machines 98/37/EEC and Efficiency 92/42/EEC.
- Page 10 TECHNICAL SPECIFICATION 2-E&F Riello Burner Specification...
- Page 11 RIELLO BURNER START-UP CYCLE NOTE: Above information provided relevant to Riello RDB Burner. The Firebird ‘S’ Range has been tested and will operate equally efficiently using Ecoflam or Sterling Burners which may also be fitted as original equipment.
-
Page 12: High Limit Thermostat
TECHNICAL SPECIFICATION 2-G Control Panel Layout The control panel is at the top front of the boiler, there are four operational indicator lights on the front of the boiler. See diagram below High Limit Thermostat Reset Button Early Alert Thermostat Over Heat Thermostat Relay Base Tank Thermostat... -
Page 13: Operating Instructions
OPERATING INSTRUCTIONS 3-A Boiler Controls Visible on the front boiler casing are • Central Heating thermostat control. • Time control - Domestic Hot Water. & Central Heating (optional). • Limit-stat reset button (see diagram on page 11). • Pressure Gauge Also indicator lights. - Page 14 OPERATING INSTRUCTIONS 3-C Burner Lockout To reset when Lock-out light shows: Press glowing reset button on burner control box. Reset Button Inside Burner Box The boiler is factory fitted with a burner control box lockout safety feature which operates automatically if a fault occurs in the burners operation. Should this occur, the R E D light on the front of the boiler control panel - See diagram on previous page - will illuminate and its cause must be investigated.
-
Page 15: Boiler Operation & Control
OPERATING INSTRUCTIONS 3-D Boiler Operation and Control Timer Switch Timer Switch Timer Switch Pos. A Pos. B Pos. C Constant Timed Boiler Operation and Control Domestic hot water production cycle commences once the timer has been set and switched on. If boiler and system are cold allow 20 - 30 minutes for domestic hot water heat store to reach working temperature. -
Page 16: Domestic Hot Water Operation
OPERATING INSTRUCTIONS Programming Guide SETTING UP The outer dial should be set to the current time. Rotate the dial slowly in a clockwise direction, until the correct hour is aligned with the arrow head printed on the dial. Note that the outer dial is printed with the 24 hour clock - 8:00 a.m. -
Page 17: Installation
INSTALLATION 4-A Standards & Regulations To ensure the highest standards of installation & safety, it is important that the boiler be installed in compliance with the following regulations where applicable. All CURRENT editions of the appropriate Building Regulations:- Part G & J England & Wales Part F, Section III Scotland Part L Northern Ireland Part J Republic of Ireland... -
Page 18: Positioning Boiler
Sound levels must also be a consideration. Whilst the Firebird Combi Range are one of the quietest boilers on the market, some householders are particularly sensitive and the following points should be considered: 1. - Page 19 INSTALLATION 4-C Flue Systems IMPORTANT Because of the improved efficiencies of boilers under E.U. Efficiency requirements and OFS A100 Standard, it is necessary to pay extra special attention to flues and chimneys. The improved efficiency figures achieved by modern oil boilers are attained by using more of the heat (higher temperatures) heretofore allowed into flues and chimneys.
- Page 20 INSTALLATION 4-D Balanced Flue Siting A. Below a gutter or sanitary pipework. B. Horizontal from opening, airbrick, window etc. C. Above ground or balcony level. D. Below eaves or balcony E. From an internal or external corner. F. From a terminal facing the terminal.
- Page 21 INSTALLATION Clearances advised by the British Standards for Open, Low Level Discharges and Balanced Flues fitted to Oil Fired Boilers Minimum distances to terminals in millimetres as measured from top of the chimney or the rim of a low level discharge opening Directly below an opening, air brick, window etc Horizontally to an opening, air brick, window etc Below a gutter, eaves or balcony with protection...
-
Page 22: Conventional Flue
INSTALLATION 4-E Ventilation and Combustion Air 1. Conventional Flue Boilers An adequate supply of combustion and ventilation air is essential for efficient and safe boiler operation and the openings for this should be positioned to cause least possible draught, with no possibility of being accidentally blocked. -
Page 23: Balanced Flue
2. Balanced Flue Boilers The Firebird boiler may be set for Room-sealed balanced flue operation using a Firebird balanced flue kit and then does not draw combustion air from inside the room. It is drawn from outside direct to burner by airpipe ☛... -
Page 24: Oil Supply
OIL SUPPLY The boiler burner is factory set to use 28-second kerosene. However, Gas oil 35-second can be used with a conventional flue installation if a PRE-HEATER is also fitted. Note: Gas Oil 35sec may not be used with a balanced flue installation. If boiler location allows use of 35 sec.Gas Oil, pump pressure should be increased and air settings readjusted as necessary. - Page 25 OIL SUPPLY 5-D Two Pipe Systems Where installations have the bottom of the tank below the oil burner pump a two pipe system is required. Ensure that valves and filters are not fitted in the return line as this must be unobstructed at all times. The oil burner pump should be set for two pipe operation as detailed in accompanying oil burner manufacturers manual, refer also to page seven of this manual - section 2E+F...
-
Page 26: Flue Systems
FLUE SYSTEMS 6-A Important Notice Because of the improved efficiencies of boilers under E.U. Efficiency requirements and OFT A100 Standard, it is necessary to pay extra special attention to flues and chimneys. The improved efficiency figures achieved by modern oil boilers are attained by using more of the heat (higher temperatures) heretofore allowed into flues and chimneys. -
Page 27: Balanced Flue Systems
IMPORTANT: THE INSTALLER MUST EXAMINE THIS ILLUSTRATION CAREFULLY BEFORE PROCEEDING WITH INSTALLATION. • Firebird do not recommend the use of a low level flue’s on white cased indoor boilers. • The Firebird low level concentric flue kit has been specifically designed for Firebird’s indoor boilers. -
Page 28: Installation Instructions
Apply high temperature sealant to the O ring on the inner flue pipe to ensure a positive seal. 6-C Concentric Flue System 5” (125mm) O.D. Concentric flue Firebird S 70,000 - 90,000 and 120,000 btu’s Boilers. Flue Extension IMPORTANT: A 50mm - (2 inch) gap must be left between cone cowl and wall. -
Page 29: Commissioning
COMMISSIONING Commissioning must be carried out by a Note: OFTEC qualified service engineer. (U.K. Only) It should be noted that it is the responsibility of the installer to ensure that the boiler is properly commissioned. Failure to do so may invalidate the boiler guarantee and any extended warranty. -
Page 30: Servicing
SERVICING Servicing must be carried out by a Note: OFTEC qualified engineer. (U.K. Only) 8-A Recommended Service Intervals 28 second oil Once annually 35 second oil Once annually Ensure that 35 secs fuel oil is only used where allowed by regulations. Burner should then be re-set for this fuel. -
Page 32: Sealed System & Domestic Hot Water
Combi Oil Boiler PART 2 Sealed System & Domestic Hot Water... - Page 33 DOMESTIC HEATING AND HOT WATER EALED EATING IRCUIT The system must comply with BS 7074 Part 1 and BS 5449 Part 1 with a maximum water temperature of 80˚C. * A manual reset overheat limit thermostat is located at the rear of the electrical control panel (see page 11).
- Page 34 1.5 bar. The Firebird Combi Boiler’s with built in Expansion Vessel’s having an initial air charge pressure of 1 bar. If total water content of system is greater than the capibilities of the vessel supplied then an additional vessel will be required to be fitted to the return pipe as close as is practicable to the boiler.
- Page 35 DOMESTIC HEATING AND HOT WATER EXPANSION VESSEL AND SYSTEM REQUIREMENTS Safety Valve Setting 3 bar Initial System Pressure 0.5 bar 1.0 bar 1.5 bar Total Water Content of System TOTAL VESSEL VOLUME ** Litres Litres Litres Litres 11.7 10.9 15.6 10.4 13.6 19.5...
- Page 36 DOMESTIC HEATING AND HOT WATER Domestic Hot Water Circuits The final 600 mm mains water supply should be of copper tube to BS 2871 Part 1. Ensure that any capillary fittings used are of lead free solder variety. For user comfort the mains pressure at taps should be between I and 5 bar.
- Page 37 Manual Filling The Firebird Combi 90 comes with this system built into the appliance. It consists of a flexible hose connection with a butterfly shut off valve at each end and a double check valve assembly at boiler end. To conform to requirements of BS 7074 Part I and local water Authority Bye Laws, the flexible hose should be disconnected at one end when filling has been completed and checked.
- Page 38 That expansion vessels are sized correctly. Special attention should be given to existing heating systems where Firebird Combi boiler has replaced an existing unit. Extra effort should be made to ensure that all original pipe work and radiators are repeatedly flushed.
- Page 39 Radiator 2 Radiator 1 Firebird Combi Boiler Kitchen Service Main Domestic Cold Feed Domestic Hot Central Heating Cold Firebird Combi System Central Heating Hot Feed & Cold Water & Expansion Storage Tank Tank Radiator 6 Radiator 5 Radiator 4 Bathroom...
- Page 40 Combi Oil Boiler PART 3 Spare Parts...
-
Page 41: Fault Finding
FAULT FINDING... -
Page 42: Spare Parts
SPARE PARTS-BURNER 10-A Burner Parts Illustration Riello RDB Burner RDB1 Firebird 70K . 3513105 501 T1K RDB1 Firebird 90K . 3513205 501 T1K RDB2 Firebird 120K . 3513605 501 T3K Riello RDB Burner Parts Code Spare Parts Description • •... - Page 43 SPARE PARTS-BOILER 10-B Combi Pluming Parts Illustration Combi 90 Boiler (Elevation) Combi 90 Boiler (Plan)
- Page 44 SPARE PARTS-BOILER 10-C Combi Pluming Parts Description ITEM COMPONENT PART No. per boiler Auto air vent FC 03010 Stat Pocket FC 03020 Filler Spring FC 03020a Locking Spring FC 03020b SIKA Flow Switch FC 03030 Safety Valve FC 03040 Manual air vent FC 03050 10 Ltr.
- Page 45 SPARE PARTS-BOILER 10-D Combi Parts Illustration Flue Gas Analysis Point For Low Level View Glass Assembley Balanced Flue Only Baffle Setup For Baffle Setup For Baffle Setup For Combi 90/120 Combi 70/90 Combi 50/70...
- Page 46 SPARE PARTS-BOILER 10-E Combi Parts Description ITEM COMPONENT PART No. per boiler Combi Boiler 50/70 - 70/90 FC 0310690 Combi Boiler 90/120 FC 0310612 Combi Tank 50/70 - 70/90 FC 0310790 Combi Tank 90/120 FC 0310712 Combustion chamber door 50/70 - 70/90 FC 0310890 Combustion chamber door 90/120 FC 0310812...
- Page 47 SPARE PARTS-BOILER 10-F Combi Control Panel Illustration...
- Page 48 SPARE PARTS-BOILER 10-G Combi Control Panel Description ITEM COMPONENT PART No. per boiler Control panel back FC 03129 Control panel front FC 03130 Control panel top FC 03131 Timer bracket FC 03132 Timer blank FC 03133 Pressure Gauge FC 03134 Bracket for pressure gauge FC 03135 Nut for pressure gauge...
-
Page 49: Commissioning Record
Commissioning Record This record should be carefully completed, remain in this manual and be left with householder. A copy should be kept on file by engineer Date: Commissioning Engineer:- Name: Tel. No: Address: Boiler:- Type Output: Fuel Used: Kerosene (28 sec) or Gas oil (35 sec) Burner:- Nozzle size: Nozzle Type:... -
Page 50: Service Report
Service Report All Information recorded hereunder should also be included in Engineers own filed service reports. It is recommended that the boiler be serviced, at least once a year, and the details recorded below. Combi Boilers may need more frequent service. Engineer should advise householder. - Page 51 Service Report All Information recorded hereunder should also be included in Engineers own filed service reports. It is recommended that the boiler be serviced, at least once a year, and the details recorded below. Combi Boilers may need more frequent service. Engineer should advise householder.
- Page 52 NOTES...
- Page 53 Firebird Boilers Guarantee Registration IMPORTANT Please ensure that the appliance is commissioned and the installer or commissioning engineer fills in the commissioning check details below, which should then be promptly returned to nearest Firebird address. FIREBIRD UK FIREBIRD BOILERS FIREBIRD PRODUCTS...
- Page 54 © RJS 1 8 2004 © Copyright applies to all FIREBIRD products. Our policy is one of continual development and we therefore reserve the right to change without prior notice the specification of our products at any time and be without obligation to make similar changes in products previously produced.
