SPARE PARTS-BOILER
10-E Combi Parts Description
ITEM COMPONENT
No.
18 Combi Boiler 50/70 - 70/90
Combi Boiler 90/120
19 Combi Tank 50/70 - 70/90
Combi Tank 90/120
20 Combustion chamber door 50/70 - 70/90
Combustion chamber door 90/120
20a Door Gasket 50/70 - 70/90
Door Gasket 90/120
21 Viewing glass bracket
21a Viewing glass
21b Viewing glass gasket
22 Flue gas analysis point blank
22a Flue gas analysis point gasket
23 Flue adapter
23a Flue adapter gasket
23b M8 x 140mm Bolt
24 50/70 - 70/90 Baffle
24b 90/120 Baffle
25L Left side panel
25R Right side panel
26 Front panel 50/70 - 70/90
Front panel 90/120
27 Top panel 50/70 - 70/90
Top panel 90/120
27a Top panel blanking plate
27b Top panel flue finishing plate
28 Drip tray
29 Foil Lagging
30 RDB Burner
30a Burner flange
30b Burner flange gasket
31 Flexible air hose
32 Control panel back
32a Control panel front 50/70 - 70/90
Control panel front 90/120
32b Control panel top
PART No.
FC 0310690
FC 0310612
FC 0310790
FC 0310712
FC 0310890
FC 0310812
FC 03109
FC 0310912
FC 03110
FC 03111
P70-L-45
FC 03113
FC 03114
FC 03115
FC 03116
FC 03117
P90-L-09
P120-L-09
FC 03118L
FC 03119R
FC 03120
FC 0312012
FC 03121
FC 0312112
FC 03122
FC 03123
FC 03124
FC 03125
See page 41
FC 03126
FC 03129
FC 03130
FC 0313012
FC 03131
45
Qty
per boiler
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
3-4
8
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
