  • Page 1 HEATING SOLUTIONS Enviromax CondEnsing BoilErs TEChniCal manual System Boiler Systempac Slimline Systempac This manual must remain with the householder once installation is complete Working towards a greener planet...
  • Page 2: Table Of Contents

    Contents FoReWoRD We would like to thank you for purchasing a high efficiency Firebird condensing oil boiler. This instruction manual is produced for the reference and guidance of qualified installation engineers, preferably OFTEC (Oil Firing Technical Association) registered. EU legislation governs the manufacture, operation and efficiency of all domestic central heating oil boilers.
  • Page 3: Safety

    saFety safety - conformity was demonstrated by meeting the HealtH & saFety inFoRMation following standards: The installer should be aware of his/her responsibilities under the current, local Health and Safety at Work Act. The EN60335-1: 2012: Household and Similar Electrical Appliances interests of safety are best served if the boiler is installed and - Safety - Part 1: general Requirements commissioned by a competent, qualified engineer, OFTEC...
  • Page 4: Standards & Regulations

    stanDaRDs & Regulations to ensure the highest standards of installation & safety, in addition, the work must comply with relevant it is important that the boiler be installed in compliance building regulations for oil fired boilers and oil storage with the following regulations where applicable. it tanks.
  • Page 5: Condensate Disposal

    2.1 - stanDaRDs & Regulations - ConDensate DisPosal Firebird condensing boilers, when in condensing mode, extract more heat from the flue products and the resulting condensate which is mildly acidic, needs to be drained from the boiler via a condensate pipe to the drainage system.
  • Page 6 2.1 - stanDaRDs & Regulations - ConDensate DisPosal systeM no. 2 - ConDensate PuMP ConDensate PuMP (kit is available as an optional extra) Condensate Pump can be positioned within the casing of the boiler on the base or fixed to the casing of the boiler house boiler, or mounted on the wall alongside the boiler.
  • Page 7 2.1 - stanDaRDs & Regulations - ConDensate DisPosal Condensate trap Fitting 1. Push screw cap into Connector connector and screw onto socket. Seal Screw cap 2. Place cone into frame and float into cone. Float Seal Cone Frame 3. Screw frame with cone and float into connector.
  • Page 8: Flue Regulations

    2.2 - stanDaRDs & Regulations - Flue Regulations BalanCeD Flue siting The terminal should be positioned to avoid combustion products entering the building or accumulating in stagnant pockets around buildings. The terminal must be protected by a guard if it is less than 2 metres above ground level or in a position where any person has access to it (i.e.
  • Page 9 BalanCeD Flue BoileRs The Firebird boiler may be set for room-sealed flue operation using a Firebird condensing balanced flue kit. This kit does not draw combustion air from inside the room. it is drawn from outside, direct to the burner by an air pipe supplied with the boiler.
  • Page 10 Please note that only Firebird flue kits should be used for flue installations.
  • Page 11: Flue Systems

    2.3 - stanDaRDs & Regulations - Flue systeMs PLUME KIT CONDENSING BOILER CHIMNEY INSTALLATION Condensing Condensing birdguard birdguard System 35 System 35 clamp plate clamp plate 80 mm 45˚ bend System 35 flexible liner System 35 flexible liner suitable for condensing suitable for condensing applications applications...
  • Page 12: Oil Supply

    2.4 - stanDaRDs & Regulations - oil suPPly oil stoRage tanK siting For installation in scotland, Building Standard Part F applies. This requires compliance with BS 5410 Part 1: Consult OFTEC Manuals 2014 and BS 5410 Part 2: 2013. All tanks either deemed to be at risk or with a capacity of more than 2,500 litres will It is unlikely that a fire will start at an oil tank.
  • Page 13: System Boiler

    3.1 systeM BoileR - HouseHolDeR/enD useR inFoRMation TO TURN THE BOILER OFF: Please consult with your installer regarding the operation of your boiler. this should include timer operation/ • Press button 4 and hold for 6 seconds until “off” appears room thermostat operation and any other additional on the LCD. operational features.
  • Page 14 3.1 systeM BoileR - HouseHolDeR/enD useR inFoRMation ERROR DISPLAy AND RE-SET systeM BoileR 35-44kW Warning: Should an error appear on the control panel display, consult your service engineer or the Firebird technical department before attempting to re-set the error. ERROR DISPLAy E1 Thermistor fault.
  • Page 15: Installer Guidelines

    12-20kW - 20-26kW - 26-35kW Sound levels must also be a consideration. Whilst Firebird condensing oil boilers are one of the quietest boilers on the Pressure relief market, some householders are particularly sensitive.
  • Page 16 3.2 systeM BoileR - installeR guiDelines 35-44kW Filling looP Connect the filling loop. Open both valves. Do not allow the unit to exceed 1 bar while filling and a maximum of 2 bar Automatic when the radiators are at full operating temperature. The air vent automatic air vent will allow air to dispel from the boiler.
  • Page 17 3.2 systeM BoileR - installeR guiDelines FlaP valve installation Balanced flue Jubilee clip Flap valve "TOP" mark "TOP" mark Snorkel Jubilee clip Correct position of flap valve 1. Push the flap valve into the balanced flue air intake. 2. Ensure that the flap valve is in the correct position.
  • Page 18 3.2 systeM BoileR - installeR guiDelines WiRing tHeRMostat teMPeRatuRe ContRol Boiler Central Heating Control: 60˚C - 80˚C electrical supply Boiler Safety Limit: 110˚C the boiler and controls require a 230v 50Hz mains electric supply protected with a 5a fuse. Tank (DHW) - Fixed: 78˚C Early Alert - Fixed 87˚C...
  • Page 19 3.2 systeM BoileR - installeR guiDelines 5 PIN (DIgITAL) SySTEM BOILER 35-44KW Please note a permanent live connection is required to operate the Pump over run thermostat 87˚C post-purge function on the burner and the pump over-run thermostat. If permanent live supply is not provided the burner will not operate. L3 permanent live Power to burner L1 switch live...
  • Page 20: Technical Details

    3.3 systeM BoileR - teCHniCal Details teCHniCal Details SySTEM BOILER 12-20KW, 20-26KW AND 26-35KW Front View Side View Top View SySTEM BOILER 35-44KW Front View Side View Top View Model - system Weight Dimensions (mm) (output range) 12-20kW 20-26kW 26-35kW 35-44kW 1048...
  • Page 21 3.3 systeM BoileR - teCHniCal Details Only for 35-44 kW No. Qty Description 12-20 kW 20-26 kW 26-35 kW 35-44 kW Tube baffle 110907 110907 110907 111503 (qty 6) Tube baffle single 110908 110908 110908 111502 (qty 8) Smoke baffle 212022 212028 212122...
  • Page 22 3.3 systeM BoileR - teCHniCal Details teCHniCal sPeCiFiCation Heat Output 12-20 + 20-26 26-35 35-44 COnneCtiOns Heating Flow 22 mm dia. 28 mm dia. 1 ½” BSP Heating Return 1” BSP 1” BSP 1 ½” BSP Mains Cold Feed (Copper) 15 mm dia.
  • Page 23: Householder/End User Information

    4.1 systeMPaC - HouseHolDeR/enD useR inFoRMation Please consult with your installer regarding the operation of your boiler. this should include timer operation/room thermostat operation and any other additional operational features. the basic features of the control panel are outlined below. Minimum Medium Maximum...
  • Page 24: Installer Guidelines

    Sound levels must also be a consideration. Whilst Firebird condensing oil boilers are one of the quietest boilers on the 12-20kW - 20-26kW - 26-35kW market, some householders are particularly sensitive.
  • Page 25 4.2 systeMPaC - installeR guiDelines 35-44kW Filling looP Connect the filling loop. Open both valves. Do not Automatic allow the unit to exceed 1 bar while filling and a air vent maximum of 2 bar when the radiators are at full operating temperature.
  • Page 26: Electrical Supply

    4.2 systeMPaC - installeR guiDelines WiRing The boiler must have a permanent power supply to enable overrun and frost protection. The hot water and central electrical supply heating should be timed separately. the boiler and controls require a 230v 50Hz mains electric supply protected with a 5a fuse.
  • Page 27 4.2 systeMPaC - installeR guiDelines Flue installation Balanced flue Jubilee clip Flap valve "TOP" mark "TOP" mark Snorkel Jubilee clip Correct position of flap valve 1. Push the flap valve into the balanced flue air intake. 2. Ensure that the flap valve is in the correct position.
  • Page 28: Technical Details

    4.3 systeMPaC - teCHniCal Details teCHniCal Details SySTEMPAC 12-20KW, 20-26KW AND 26-35KW Front View Side View Rear View Base SySTEMPAC 35-44KW Front View Side View Rear View Base Model - systempac Weight Dimensions (mm) (output range) 12-20kW 20-26kW 26-35kW 35-44kW...
  • Page 29 4.3 systeMPaC - teCHniCal Details Only for 35-44 kW No. Qty Description 12-20 kW 20-26 kW 26-35 kW 35-44 kW Tube baffle 110907 110907 110907 111503 (qty 6) Tube baffle single 110908 110908 110908 111502 (qty 8) Smoke baffle 212022 212028 212122 211651 (qty 8)
  • Page 30 4.3 systeMPaC - teCHniCal Details teCHniCal sPeCiFiCation Heat Output 12-20 + 20-26 26-35 35-44 COnneCtiOns Heating Flow 22 mm dia. 28 mm dia. 1 ½” BSP Heating Return 1” BSP 1” BSP 1 ½” BSP Mains Cold Feed (Copper) 15 mm dia. 15 mm dia.
  • Page 31: Slimline Systempac

    5.1 sliMline systeMPaC - HouseHolDeR/enD useR inFoRMation Please consult with your installer regarding the operation of your boiler. this should include timer operation/room thermostat operation and any other additional operational features. the basic features of the control panel are outlined below. Minimum Medium Maximum...
  • Page 32: Installer Guidelines

    CH return Sound levels must also be a consideration. Whilst Firebird condensing oil boilers are one of the quietest boilers on the market, some householders are particularly sensitive.
  • Page 33 5.2 sliMline systeMPaC - installeR guiDelines Filling looP WiRing electrical supply Connect the filling loop. Open both valves. Do not allow the unit to exceed 1 bar while filling and a maximum of 2 bar the boiler and controls require a 230v 50Hz mains when the radiators are at full operating temperature.
  • Page 34 5.2 sliMline systeMPaC - installeR guiDelines Flue installation Balanced flue Jubilee clip Flap valve "TOP" mark "TOP" mark Snorkel Jubilee clip Correct position of flap valve 1. Push the flap valve into the balanced flue air intake. 2. Ensure that the flap valve is in the correct position.
  • Page 35: Technical Details

    5.3 sliMline systeMPaC - teCHniCal Details teCHniCal Details Front View Side View Rear View Base Front Dimensions (mm) Model - slimline systempac Weight (output range) 12-20kW 20-26kW 26-35kW...
  • Page 36 5.3 sliMline systeMPaC - teCHniCal Details No. Qty Description 12-20 kW 20-26 kW 26-35 kW Tube baffle 110907 110907 110907 Tube baffle single 110908 110908 110908 Smoke baffle 212022 212028 212122 Door seal 111314 111314 111314 Door duroboard 110918 110918 110918 Flue gasket 112104...
  • Page 37: Technical Specification

    5.3 sliMline systeMPaC - teCHniCal Details teCHniCal sPeCiFiCation Heat Output 12-20 20-26 26-35 COnneCtiOns Heating Flow 22 mm dia. 22 mm dia. 28 mm dia. Heating Return 1” BSP 1” BSP 1” BSP Mains Cold Feed (Copper) 15 mm dia. 15 mm dia.
  • Page 38: Commissioning & Burner Settings

    Firebird within 28 days of installation (this can also be done online on the Firebird website). a copy should be retained by the commissioning engineer. u the system should be checked thoroughly.
  • Page 39: Handing Over

    Set the air to what is required for the nozzle size +. 5 • The boiler passport. on the dial - example: the factory setting for a Firebird 26kW has a Danfoss .65 80° ES nozzle with a pump The householder should be advised to: pressure of 9 bar and air at 2.5.
  • Page 40 The burner nozzle, pump pressure and air setting may have to be changed from the factory setting to suit site conditions. KeRosene settings FoR FiReBiRD BoileR Range using RDB 2.2 BuRneRs variations in nozzle throughput, flue type & draught, oil viscosity etc. may give results differing from the below laboratory performance figures.
  • Page 41: Servicing

    1. Carry out a combustion analysis. 2. Follow the steps as set out in the burner set-up Cleaning a Firebird condensing boiler: section. 3. Check safety operation, pull out the photo cell, 1. Remove all baffles, including the tubular baffles in cover and make sure the burner locks out.
  • Page 42: Terms & Conditions Of Warranty

    8. Firebird will not accept any liability in respect of any u Correct commissioning will ensure that your boiler is defect occurring to the product due to limescale set to operate at its maximum fuel efficiency.
  • Page 43: Product Fiche

    PRoDuCt FiCHe ErP A Rated Seasonal Annual energy Rated heat output Efficiency Sound power level Energy consumption Model Base Model efficiency Identifier class SYSTEM 12-20kW 20-26kW 26-35kW 36-44kW SYSTEMPAC 12-20kW 20-26kW 26-35kW 36-44kW SliMlinE SYSTEMPAC 12-20kW 20-26kW 26-35kW...
  • Page 44 © Copyright applies to all FIREBIRD products. Our policy is one of continual development and we therefore reserve the right to change without prior notice the specification of our products at any time and be without obligation to make similar changes in products previously produced.
