Balanced Flue; Electrical Supply - FireBird Combi Range Installation Commissioning Servicing & User Instructions

The Firebird boiler may be set for Room-sealed balanced flue operation using
a Firebird balanced flue kit and then does not draw combustion air from
inside the room. It is drawn from outside direct to burner by airpipe
☛ supplied with boiler. Flue gases are expelled in the same way. However, if
the boiler is installed in a compartment or small room, some ventilation air
☛
Balanced flue boiler in room (eg. kitchen) does not require individual ventilation.
BALANCED - FLUE BOILERS IN COMPARTMENTS
HVCA Codes of Practice and BS 5449: Part 1 "Forced Circulation Hot Water
Systems" should be adhered to when installing the boiler. Refer also to
The boiler and controls require 230V 1 phase 50Hz electric supply
A qualified electrician must carry out all electric wiring in accordance with
current I.E.E Regulations and any local regulations which may apply.
The mains electrical supply must be taken from a double pole isolating switch
with a 5amp fuse, positioned somewhere close to the boiler. Heat resisting
cable must be used which can be routed into the boiler through the access
4
INSTALLATION
2. Balanced Flue Boilers
is necessary to maintain acceptable temperature in boiler area
4-F Domestic Heating & Hot Water Systems
Regulations and Standards listed on page 14.

Electrical Supply

with a 5amp fuse.
THIS APPLIANCE MUST BE EARTHED.
provided on either side of the base.
Ancillary controls may be provided for with terminal connections
in the control panel.
4-E
22
☛
☛
